4.2.

Client Side Connection Descriptors

Section Title
Connections
Column Title
Specify through which port the device is
Port
connected to the FieldServer
Baud* Specify baud rate
Parity* Specify parity
Data_Bits*
Specify data bits
Stop_Bits*
Specify stop bits
Protocol
Specify protocol used
Handshaking* Specify hardware handshaking
Example
Client Side Connections
//
Connections
Port,
P1,
4.3.

Client Side Node Descriptors

Section Title
Nodes
Column
Title
Node_Name Provide name for Node
Generic Node ID unique to port. Also used as panel
Node_ID
number.
Protocol Specify protocol used
Specify which port the device is connected to the
Port
FieldServer
Example
// Client Side Nodes
Nodes
Node_Name,
Node_1,
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll Free: 888-509-1970 email: support@fieldserver.com
Function
Protocol,
Secutron,
Function
Node_ID,
1,
P1-P8
150, 300, 1200, 2400, 4800, 9600
(Vendor limitation)
None (Vendor limitation)
8 (Vendor limitation)
1 (Vendor limitation)
Secutron
None
Baud, Parity,
9600, None,
Protocol,
Secutron,
Page 6 of 15
Legal Values
1
Handshaking
None
Legal Values
Up to 32 alphanumeric
characters
0-999
Secutron
1
P1-P8
Connection
P1
