- Page 1 A Sierra Monitor Company Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8700-36 Weigh-Tronix APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after May 1, 2001 Instruction Manual Part Number FS-8700-36 Version: N/A 2/18/2004...
-
Page 2: Table Of Contents
2.1.2.1 Data Arrays...3 2.1.2.2 Client Side Nodes...4 2.1.2.3 Client Side Map Descriptors ...5 FieldServer Technologies 1991 Tarob Court, Milpitas, CA 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Table of Contents ... 1 ... 2 E-mail: support@fieldserver.com Page Index... -
Page 3: Weigh-Tronix Description
FS-8700-36 Weigh-Tronix 1. Weigh-Tronix Description The Weigh-Tronix driver allows the FieldServer to transfer data to and from devices over either RS-232 or RS-485 using Weigh-Tronix protocol. The FieldServer emulates a Client only. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer. -
Page 4: Fieldserver As A Weigh-Tronix Client
Enter the following program sub com1_message fmtprint (1) end sub getcom$(1) end sub Close editor Editors/print formats FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com DB25M Customer Responsibility N1 N2 RS485 10 Base T... -
Page 5: Configuration File Structure
Data_Format Data_Array_Length Example Data Arrays Data_Arrays Data_Array_Name, DA_AI, FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Provide name for Data Array Provides data format Number of Data Objects Data_Format, Data_Array_Length Float, E-mail: support@fieldserver.com... -
Page 6: Client Side Nodes
Example Client Side Nodes Nodes Node_Name, Protocol, Scale1, Weigh-Tronix, FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Specify which port the device is connected to the FieldServer Specify baud rate... -
Page 7: Client Side Map Descriptors
// Client Side Map Descriptors Map_Descriptor Map_Descriptor_Name, Data_Array_Name, Data_Array_Location, Function, Node_Name, Address, Length wtio_MAP, DA_AI, FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Function Name of this Map Descriptor Name of Data Array where... - Page 8 FS-8700-36 Weigh-Tronix 3. Revision History Date Driver Version 04/22/02 1.00d 2/18/04 1.00d FieldServer Technologies 1991 Tarob Court, Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042 Visit our website: www.fieldserver.com Document Comment Revision Revision history added Releasing E-mail: support@fieldserver.com Page 6...
