FS-8700-72 Secutron Manual
4.

Configuring the FieldServer as a Secutron Modul-R driver Client

For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration
Manual. The information that follows describes how to expand upon the factory defaults provided in the
configuration files included with the FieldServer (See ".csv" files on the provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to
communicate with Secutron Modul-R panels.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order
to enable the FieldServer for Secutron Modul-R driver communications, the driver independent
FieldServer buffers need to be declared in the "Data Arrays" section, the destination device addresses
need to be declared in the "Client Side Nodes" section, and the data required from the Servers needs to
be mapped in the "Client Side Map Descriptors" section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
4.1.

Data Arrays/Descriptors

Section Title
Data_Arrays
Column Title
Data_Array_Name
Data_Format
Data_Array_Length
Example
// Data Arrays
Data_Arrays
Data_Array_Name,
p1c1_devices,
p1c1_function,
p1c69_restart,
p1c69_function,
p1c90_reset,
p1c90_function,
The Poller Data Array will contain non-zero data when communications with the panel is OK.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll Free: 888-509-1970 email: support@fieldserver.com
Function
Provide name for Data Array
Provide data format. Each Data Array can only take
on one format.
Number of Data Objects. Must be larger than the data
storage area required for the data being placed in this
array.
Data_Array_Format,
Bit,
Byte,
Bit,
Byte,
Bit,
Byte,
Page 5 of 15
Legal Values
Up to
alphanumeric
characters
Bit, Byte, Packed_Bit,
Uint16
1-10,000
Data_Array_Length
1
1000
1000
100
100
100
15
