FS-8700-72 Secutron Manual
Appendix A. Advanced Topics
Appendix A.1.
When the Client driver receives an event from the panel, it stores the event's function or condition
code in the Secutron_Type=function Map Descriptor's Data Array at the device number's offset,
Example:
Device=3 on Circuit=1 goes into alarm – the Panel reports an event with function code A (Decimal 65)
The Map Descriptor Secutron_Type=device, Secutron_Circuit=1 will set a bit and store the event
function code A (Decimal 65) at offset 3 in the Map Descriptors' Data Array.
The Secutron_Type=device Map Descriptors will set a bit if any of the events listed below occur on
that circuit or zone. The bit will be cleared if the panel reports the event as cleared.
The full list of event function codes are:
ASCII value
Decimal
65
A
B
66
C
67
D
68
E
69
G
71
H
72
I
73
J
74
M
77
N
78
P
80
Q
81
R
82
S
83
T
84
U
85
W
87
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll Free: 888-509-1970 email: support@fieldserver.com
Event Function or Condition Codes
Meaning
Alarm
Bypass
Comlink
Duplicate Addressable Device
Maintenance Alert
Ground Fault
Hot Key Pressed
Illegal Addressable Device
Switch
Missing Addressable Device
Non-Fire/Non-Reporting
Pull Station Alarm
Releaser Abort
Releaser Halt
Supervisory
Trouble or Parameter Change
Wrong Device Type
Waterflow Alarm
Page 12 of 15
