FS-8700-127 Hanning & Kahl HCS-R Manual
5.

Configuring the FieldServer as a HCS-R Server

For a detailed discussion on FieldServer configuration, please refer to the FieldServer
Configuration Manual. The information that follows describes how to expand upon the factory
defaults provided in the configuration files included with the FieldServer (See ".csv" sample files
provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer
to communicate with a Hanning & Kahl HCS-R Client.
The configuration file tells the FieldServer about its interfaces, and the routing of data required.
In order to enable the FieldServer for HCS-R communications, the driver independent
FieldServer buffers need to be declared in the "Data Arrays" section, the FieldServer virtual
Node(s) needs to be declared in the "Server Side Nodes" section, and the data to be provided to
the clients needs to be mapped in the "Server Side Map Descriptors" section. Details on how to
do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the
default.
5.1.

Server Side Connection Descriptors

Section Title
Connections
Column Title
Port
Protocol
Baud*
Parity*
Data_Bits*
Stop_Bits*
Handshaking*
Server_Hold_Timeout*
Example
Server Side Connections
//
Connections
Port,
P8,
3
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: 408 262-2299 Fax: 408-262-2269 Toll_Free: 888-509-1970 email: support@FieldServer.com
Specify which port the
connected to the FieldServer
Specify protocol used
Specify baud rate
Specify parity
Specify data bits
Specify stop bits
Specify hardware handshaking
Specifies the time that the FieldServer
will reserve the Server side connection
while waiting for the Client side to
update
data
necessary)
Protocol,
HCS-R,
Function
device is
in
Data_Array
(if
Baud,
Parity,
9600,
None,
Page 11 of 17
Legal Values
3
P1-P8
HCS-R
HCSR
H&K HCS-R
9600 (Vendor Limitation)
None (Vendor Limitation)
8 (Vendor Limitation)
1
None (Vendor Limitation)
>1.0s, 2.0s
Handshaking
None
