8
Displaying VLAN
Information
Top-Level Menu
system
ethernet
fddi
display
atm
mode
bridge
ipFragmentation
ip ipxSnapTranslation
ipx
addressThreshold
appletalk
agingTime
snmp
stpState
analyzer stpPriority
summary
script
stpMaxAge
detail
logout
stpHelloTIme
define
stpForwardDelay
modify
stpGroupAddress
remove
port
packetFilter
vlan
A
DMINISTERING
This chapter describes how to display information about VLANs and how to
configure VLANs.
Through the Administration Console, you can:
Display summary or detailed information on VLANs
Define or modify a VLAN definition
Delete a VLAN definition
You can display a summary of VLAN information or a detailed report. When
you display a summary, you receive information about the protocols and
ports assigned to each VLAN plus the layer 3 addresses used to manage
flood domains for overlapping IP subnets. The detailed VLAN report includes
the summary information plus additional utilization statistics.
From the top level of the Administration Console, enter:
bridge vlan summary
or
bridge vlan detail
The VLAN information is displayed in the format you specified.
Example of a summary display for several VLANs:
Select menu option (bridge/vlan): summary
Index Protocol
1 default
2 IP
3 IPX
4 IP
VLAN
Identifier Ports
0 1-17
2 1, 5-7
3 8-10
4 7, 12-15
S
