Defining VLAN
Information
Top-Level Menu
system
ethernet
fddi
display
atm
mode
bridge
ipFragmentation
ip ipxSnapTranslation
ipx addressThreshold
appletalk
agingTime
snmp
stpState
analyzer
stpPriority
summary
script stpMaxAge
detail
logout
stpHelloTIme
define
stpForwardDelay
modify
stpGroupAddress
remove
port
packetFilter
vlan
Table 8-1 Fields for VLAN Information (continued)
Description
Field
inPackets Number of flooded broadcast and multicast packets that were
received on the VLAN
inBytes Number of flooded broadcast and multicast bytes that were
received on the VLAN
outPackets Number of flooded broadcast and multicast packets transmitted
over the VLAN
outBytes Number of flooded broadcast and multicast bytes transmitted over
the VLAN
Follow these steps to create a VLAN definition:
1 From the top level of the Administration Console, enter:
bridge vlan define
2 Enter the appropriate protocol suite:
DECnet, SNA, Banyan, X.25, NetBIOS, NetBEUI, default
3 Enter the VLAN interface identifier.
4 Enter the VLAN name, enclosed in quotation marks.
5 Enter the number(s) of the port(s) or
You are prompted to enter the number(s) of the port(s) that can be
assigned to the VLAN.
If you did not choose the IP protocol suite for this VLAN, you have
completed the steps for defining the VLAN.
If you selected the IP protocol suite, follow these steps:
1 Enter to use layer 3 subnet addressing and continue with steps 2
defined
and 3, OR enter
undefined
2 Enter the IP subnet address.
3 Enter the subnet mask.
Defining VLAN Information
(IP, IPX, AppleTalk, XNS,
to assign all ports to the VLAN.
all
to not use layer 3 addressing.
8-3
)
