Maintaining the printer
5
6
7
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Lift the printhead cartridge up and off the swing arm (step 2 in
Remove the printhead cables.
– Push the black locking tabs to the side. Remove the gray connector of the
printhead data cable from the printhead cartridge (see
– Pull firmly on the white connector of the printhead power cable to remove it
from the printhead cartridge. You can gently pull on the wires attached to the
plug if needed to remove the cable.
Data cable
Figure 4-17: Printhead cables and connectors
Remove the ground cable connector from the ground tab of the swing arm by
pulling on the red sleeve (see
Figure 4-18: Printhead ground cable
Power cable
Ground cable
Figure 4-18).
4-17
Figure 4-16).
Figure 4-17).
