Troubleshooting
The topcoat shows lines
along the length of the
card.
A short edge of the
topcoat does not stick to
the card.
The card shows irregular
lighter or darker spots.
#
Obtain guidance from service before performing this task.
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Table 5-2: Topcoat quality problems—print ribbon
What you see Possible causes
The printhead intensity is
too high.
The printhead is not
aligned correctly.
The printhead intensity is
too low.
The printhead is not
aligned correctly.
The topcoat panel of print
ribbon is wrinkling
because the intensity
setting is too high.
The printhead is not
aligned correctly.
5-15
Solutions
Lower the printhead
intensity setting for
topcoat. See the e-Guide.
Contact your service
representative.
Increase the printhead
intensity setting for
topcoat. See the e-Guide.
Contact your service
representative.
Lower the printhead
intensity setting for
topcoat. See the e-Guide.
Contact your service
representative.
#
#
#
