DataCard ImageCard Magna User Manual page 154

C-4
Set up a Universal Serial Bus (USB) port
1
2
3
4
5
6
7
8
Right-click on the My Computer icon on the desktop and then select Properties
from the popup menu. The System Properties dialog box appears.
Select the Device Manager tab to view a list of devices. (On Windows 2000 and
Windows XP, select the Hardware tab and then click the Device Manager button.)
Select "View devices by type" if needed.
Click the + next to Universal Serial Bus controllers to display the USB port
controllers.
Click USB Root Hub, and then select the Properties button. (On Windows 2000
and Windows XP, right-click USB Root Hub and then select Properties from the
pop-up menu.) The USB Root Hub Properties dialog box appears.
Make sure that the device is enabled.
– For Windows 2000, Me, and 98 make sure that "Disable in this hardware
profile" is not selected.
– On Windows XP, make sure that "Use this device (enable)" is selected from
the Device Usage drop-down menu.
Click OK to close the dialog box.
Click the other entry, which includes the name of the installed USB device and
ends with "Host Controller," and then select the Properties button. (On Windows
2000 and Windows XP, right-click USB Host Controller and then select Properties
from the pop-up menu.) The Properties dialog box appears.
– Make sure that the device is enabled:
• For Windows 2000, Me, and 98 make sure that "Disable this hardware
profile" is not selected.
• On Windows XP, make sure that "Use this device (enable)" is selected
from the Device Usage drop-down menu.
– Click the Resources tab (see
show "No conflicts."
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Figure C-2). The "Conflicting device list" should
