Lantronix SLC8 Manager User Manual page 291

8. In the Save As dialog box, do one of the following:
a. To place the snap-in in the Administrative Tools folder, in File name box, type a name for
the snap-in, and then click Save.
b. Or, to save the snap-in to a location other than the Administrative Tools folder, in Save in,
navigate to a location for the snap-in. In File name, type a name for the snap-in, and then
click Save.
SLC™ Console Manager User Guide
Figure I-5 Console Root
Figure I-6
Figure I-6 Administrative Tools Folder
Figure I-7 shows the directory that displays.
Appendix I: LDAP Schemas
shows the folder that displays.
291
