Using the Scroller Editor

The scroller and wheel picker allows you to choose a specific scroll, color wheel, gobo wheel, or
effect wheel from standard manufacturers and associate them with fixtures. You may also create
customized scrolls or wheels using the editor to match custom devices installed in your fixture.
N o t e :
U s i n g t h e P i c k e r
Default color and pattern media for the selected fixture, as determined in the fixture library, is
displayed in the {Attributes} page. Only the media attribute that is available for the selected fixture
will display.
In the sample image below, the selected channel (1) is a Source Four Revolution with a color
scroller. If the selected channel included a color wheel and two gobo wheels, each device would be
represented in the display with a button.
The picker displays on the left half of the CIA when you select the specific attribute ({Scroller},
{Color Wheel}, {Gobo Wheel}, or {Effect Wheel}). The picker displayed is specific to the selected
attribute (the scroll picker will display when {Scroller} is clicked, the color wheel picker will display
when {Color Wheel} is clicked, and so on).
5
Patch
Scrollers and wheels can be created before being patched. All attributes will be
available.
Select the scroll or wheel type.
