Element Configuration Utility Reference

During the boot process, a countdown timer will appear near the Element logo. There are two ways
that you can force the console to boot into the utility instead of the main console application. You
can either click with a mouse the countdown timer itself or you can hold down "e", "o" and "s" at the
same time on a connected alphanumeric keyboard. You have 5 seconds to do either one if you want
to go directly to the configuration utility.
Otherwise, you can always enter the ECU from the Element application by choosing
[Browser]>Exit Element.
S t a r t i n g S c r e e n
Click to get started.
Clicking Client assigns
this console as a client.
Clicking Offline will put
the console in offline
mode and will not interact
on the network with other
devices.
This is the starting screen of the utility. From here you can choose to boot the console in one of
three different modes, change various settings, or shutdown the console.
S t a r t E l e m e n t
This is the basic startup mode for Element.
E l e m e n t C l i e n t
A device set to client mode can act as a remote video station for a system. A client device cannot
output to the lighting system. A client is always in mirror mode.
E l e m e n t O f f l i n e
Offline mode puts the software in a state where there is no network activity, no control, no
connections with any other network devices.
This mode is primarily intended for offline editing of a show file.
210
Element Welcome Screen / Element Configuration Utility Entry Point
Clicking Settings will take you to the
settings and screens of the Element
Configuration Utility (ECU) described
below.
Clicking Shutdown will shutdown the
Element console after a confirmation.
See "Mirror Mode" on page 233.
