Wiring Diagrams - Trane Wired Temperature Sensors Installation, Operation And Maintenance Manual

Wiring Diagrams

Each wiring diagram is identified by sensor part number (see
For wiring information for the display sensor, see
X1351152701
X1351152801
X1351152901
BAS-SVX10C-EN
R1, 1.5 kΩ
Timed Timed
override override
Unoccupied Occupied
(Cancel) SW2 (On) SW1
Setpoint
potentiometer
Ω
Pot 1, 1 k
Dwg. source: 3270 3435 B
RT1 thermistor,
Ω
10 k at 25°C
Dwg source: 3270 3436
Setpoint potentiometer
Ω
Pot 1, 1 k
Dwg source: 3270 3437
"Part Numbers, " p. 6
Figure 1, p. 10.
RT1
thermistor,
Ω
10 k at 25°C
Calibration potentiometer
Pot 2 (see Note )
NOTE: POT 1 and POT2 are factory calibrated.
Field adjustment voids warranty.
Zone temperature
1
Signal common
2
RT1 thermistor,
Ω
10 k at 25°C
Calibration potentiometer
Pot 2 (see Note )
Note: Pot 1 and Pot 2 are factory
calibrated. Field adjustment voids
warranty.
for reference.)
Zone temperature
1
Signal common
2
Setpoint
3
Zone temperature
1
Signal common
2
Setpoint
3
