Display Sensor Operation

This section describes display sensor operation.
that has been configured and is in operating mode.
Figure 5. Display sensor in operating mode
Occupancy indicator/Error code

Changing Temperature Settings

This symbol shows the current room
temperature, or your temperature setting,
.
while you are making an adjustment.
When you select a setpoint, this symbol
appears.

Changing Heating and Cooling Temperature Settings (dual setpoint systems only)

Some systems allow you to select both heating and
cooling room temperature settings. If your system
has this option, this symbol appears when you
adjust the temperature setting.
When you adjust the cooling setting, the top arrow
and snowflake flash.
When you adjust the heating setting, the bottom
arrow and flame flash.
BAS-SVX10C-EN
Temperature
System settings
Fan settings
Keypad
1. To increase the room temperature, press
To decrease the room temperature, press
2. To confirm, press
to the home screen.
1. Press
2. If in cooling mode, press
heating mode, press
3. Press
4. To confirm, press
will appear.
Note: The heat/cool setpoint offset (deadband) chosen during
Figure 5 shows an example of a display sensor
.
or wait 5 seconds. The display will return
or to select the heating/cooling setting.
to change to heating mode. If in
to change to cooling mode.
or to select the heating/cooling setting.
or wait 5 seconds. The home screen
configuration will apply.
