Service Pin Request

Some sensor models can communicate a service pin request to their connected unit controller.

Sensors with Occupied/Unoccupied Buttons

To initiate a service pin request, press the Occupied button
following occurs:
•
•

Display Sensor

To initiate a service pin request, the sensor must be configured to support occupancy and must be
in operating mode (see
To initiate a service pin request:
1. With the sensor in operating mode, navigate to the occupancy menu.
2. Press the right arrow on the keypad
3. Press and hold the center button for 10 seconds. The following occurs:
Figure 3. Location of keys for service pin request
BAS-SVX10C-EN
Space temperature output is driven to 10 Ω (nominal).
The output generates for 15 seconds.
"Configuring the Display Sensor, " p.
unoccupied symbol leaves the screen.
• The wrench symbol
• A service pin request is initiated.
• Space temperature output is driven to 10 Ω (nominal).
• The output generates for 15 seconds.
• After 15 seconds, the wrench symbol disappears.
Center button
(Figure 2, p.
11).
(Figure 3). The occupied symbol remains on the screen; the
appears.
Operation
24) for 10–25 seconds. The
Right arrow key
25
