Installation Guide
CO
Sensing Kit
2
Used with:
IntelliPak™ I 20-130 Ton Rooftops,
Air Handler 2-9 Casings
IntelliPak™ II 90-162 Ton Rooftops,
Air Handler A-C Casings
Model:
BAYCO2K011A (Wall Mounted)
BAYCO2K012A (Duct Mounted)
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
May 2022
Used with:
S_HJ - 090-162
S_HF, S_HL: 20-75
W_HC - A, B, C
W_HB, W_HE: Case 2-9
SAFETY WARNING
RT-SVN09E-EN
Advertisement
Related Manuals for Trane BAYCO2K011A
Summary of Contents for Trane BAYCO2K011A
- Page 1 IntelliPak™ I 20-130 Ton Rooftops, Air Handler 2-9 Casings IntelliPak™ II 90-162 Ton Rooftops, Air Handler A-C Casings Model: Used with: BAYCO2K011A (Wall Mounted) S_HJ - 090-162 S_HF, S_HL: 20-75 BAYCO2K012A (Duct Mounted) W_HC - A, B, C W_HB, W_HE: Case 2-9 SAFETY WARNING Only qualified personnel should install and service the equipment.
-
Page 2: Warnings, Cautions, And Notices
(Global Harmonized System of Classification and compounds have the same potential impact to the Labeling of Chemicals) guidelines for information on environment. Trane advocates the responsible handling of allowable personal exposure levels, proper all refrigerants-including industry replacements for CFCs respiratory protection and handling instructions. -
Page 3: Revision History
Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change. -
Page 4: Parts List
2. Check carefully for any shipping damage. If any damage is found it must be reported immediately and a claim made against the transportation company. Parts List sensor as follows: BAYCO2K011A (Wall Sensor), BAYCO2K012A (Duct Sensor) • 1 - CO... -
Page 5: Installation
Installation 2. Remove the back plate from the sensor and thread the power wires and output signal wire through the hole in WARNING the back plate (Figure 1, p. 5). For surface wiring, make Hazardous Voltage! cut-outs with pliers to the thinner section of the upper or lower edge of the back plate and to thread the wires Disconnect all electric power, including remote disconnects before servicing. - Page 6 Installation 3. Attach the mounting plate to the duct Figure 2. duct sensor wall with four screws. 4. Insert the sensor through the mounting plate, adjusting the depth for optimal air sensing. 5. If conduit is required, remove the wiring grommet and install the supplied 1/2-inch National Pipe Thread (NPT) conduit fitting.
- Page 7 Installation Wiring the Sensor - IntelliPak I 1. Wire the sensor to the unit according to the Note: The 1XD25 terminals are factory wired to the 1KF11 board. following table. Wall sensor Unit 1XD25-1 1XD25-2 1XD25-3 Figure 4. Wiring from the CO wall sensor to the unit RT-SVN09E-EN...
- Page 8 Installation RT-SVN09E-EN...
