Trane BAYSENS050m Installation Manual

Trane BAYSENS050m Installation Manual

Wireless display sensor and receiver 3 - 25 1/2 ton rooftop units 6 - 25 ton split system units
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation Guide
Wireless Display Sensor and
Receiver
3 - 25 ½ Ton Rooftop Units
6 - 25 Ton Split System Units
Model Number:
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
June 2020
BAYSENS050m
ACC-SVN129D-EN
SAFETY WARNING

Advertisement

loading
Need help?

Need help?

Do you have a question about the BAYSENS050m and is the answer not in the manual?

Questions and answers

Related Manuals for Trane BAYSENS050m

Summary of Contents for Trane BAYSENS050m

  • Page 1 3 - 25 ½ Ton Rooftop Units 6 - 25 Ton Split System Units Model Number: BAYSENS050m SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.

  • Page 2: Warnings, Cautions, And Notices

    Follow proper lockout/tagout procedures to ensure the power cannot be inadvertently energized. For variable frequency drives or other energy storing components provided by Trane or others, refer to the appropriate manufacturer’s literature for allowable waiting periods for discharge of capacitors. Verify with an appropriate voltmeter that all capacitors have discharged.

  • Page 3: Revision History

    Non-Trane personnel should always follow local regulations. Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.

  • Page 4: Installation Kit

    Introduction InstallationKit The installation kit includes the following: • Wireless Receiver • Wireless Zone Sensor • Wire Harness • Mounting Bracket • Two #8-32 x ½" Pan Head Screws • Two #6-32 x ½" Pan Head Screws • Two #10-32 x ½" Pan Head Screws ACC-SVN129D-EN...

  • Page 5: Installation

    Installation 1. Before beginning installation, remove power from the Unit. 2. Check to make sure all necessary parts were included in the kit. 3. 12 ½ - 25 ton units: Use the two #8-32 x ½" screws to mount the bracket to holes in front of the ReliaTel RTRM board in the Voyager control box.
  • Page 6 Installation Figure 2. 3-10 Ton Packaged Rooftop Units Figure 3. 6-7½ Ton Split System Units ACC-SVN129D-EN...
  • Page 7 Installation Figure 4. 10-12½ Ton Split System Units Figure 5. 15-25 Ton Split System Units ACC-SVN129D-EN...
  • Page 8 Installation 4. Remove the cover from the Wireless Receiver by firmly pressing the thumb tab at the bottom of the cover and pulling the cover away from the back plate. 5. Arrange the receiver back plate on the mounting bracket so that the release thumb tab is at the top of the bracket.
  • Page 12 For more information, please visit trane.com or americanstandardair.com. Trane and American Standard have a policy of continuous product and product data improvement and reserve the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
