Table 1.
Zone or setpoint temperature
**
55°F (12.8°C)
60°F (15.6°C)
65°F (18.3°C)
70°F (21.1°C)
75°F (23.9°C)
80°F (26.7°C
85°F (29.4°C)
*
Notes:
1. Sensors are calibrated at 70°F (21.1ºC).
2. Single setpoint systems: Varies ±28
Table 2.
Fan mode
Auto or invalid
Auto or invalid
Auto or invalid
Auto or invalid
Auto or invalid
On
On
On
On
On
High
Med
Low
Auto
Off
BAS-SVX10C-EN
Resistance measurements for zone temperature and setpoints
(29.4ºC). Dual setpoint systems: Cooling setpoint varies ±10
scale. Heating setpoint varies ±20
Resistance measurements for fan and system modes
Maintenance and Troubleshooting
Nominal zone temperature
output resistance
NA
17.47 kΩ
15.3 kΩ
13.5 kΩ
11.9 kΩ
10.5 kΩ
9.3 kΩ
8.25 kΩ
NA
Ω
at 70°F (21.1ºC); varies ±128
Ω
at 70ºF (21.1ºC); varies at ±110
Ω
at 70ºF (21.1ºC); varies at ±120
System mode
Emergency heat
Heat
Auto
Off
Cool
Emergency heat
Heat
Auto
Off
Cool
Invalid (fan control only)
Invalid (fan control only)
Invalid (fan control only)
Invalid (fan control only)
Invalid (fan control only)
Nominal setpoint and heating
setpoint output resistance
938 Ω
792 Ω
695 Ω
597 Ω
500 Ω
403 Ω
305 Ω
208 Ω
49 Ω
Ω
at endpoints of scale 55ºF (12.8ºC) and 85ºF
Ω
at endpoints of
Ω
at endpoints of scale.
Nominal output resistance
35,000 Ω
19,480 Ω
7680 Ω
2320 Ω
4870 Ω
43,450 Ω
27,930 Ω
16,130 Ω
10,770 Ω
13,320 Ω
16,130 Ω
13,320 Ω
10,770 Ω
2320 Ω
4870 Ω
