Summary of Contents for Supero SUPERSERVER 1027R-N3RF

  • Page 1 UPER ® SUPERSERVER 1027R-N3RF USER'S MANUAL Revision 1.0a...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 1027R-N3RF Installation and maintainance should be performed by experienced technicians only. The SuperServer 1027R-N3RF is a high-end server based on the SC116TS-R700WBP 1U rackmount chassis and the X9DRW-3F dual processor serverboard.
  • Page 4 SUPERSERVER 1027R-N3RF USER'S MANUAL Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the SC116TS-R700WBP server chassis. You should follow the procedures given in this chapter when installing, removing or reconfi guring SAS/SATA or peripheral drives and when replacing system power supply units and cooling fans.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    SUPERSERVER 1027R-N3RF USER'S MANUAL Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SAS/SATA ...................... 1-2 Onboard Controllers/Ports ................1-3 Graphics Controller ..................1-3 Other Features ....................1-3 Server Chassis Features ................1-3 System Power ....................
  • Page 7 Table of Contents Inner Rails ....................... 2-6 Outer Rails ...................... 2-7 Checking the Serverboard Setup ..............2-10 Checking the Drive Bay Setup ...............2-11 Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 UID ........................
  • Page 8 SUPERSERVER 1027R-N3RF USER'S MANUAL Chapter 5 Advanced Serverboard Setup Handling the Serverboard ................5-1 Precautions ..................... 5-1 Unpacking ....................... 5-1 Processor and Heatsink Installation..............5-2 Installing a Passive CPU Heatsink ..............5-6 Removing the Heatsink ................... 5-7 Connecting Cables ..................5-7 Connecting Data Cables .................
  • Page 9 Table of Contents Chapter 7 BIOS Introduction ...................... 7-1 Starting the Setup Utility ................. 7-1 Main Menu ...................... 7-1 System Time/System Date ................7-2 Advanced Settings Menu ................7-2 Event Logs ....................7-22 IPMI ....................... 7-24 Boot ....................... 7-26 Security ......................7-27 Save &...
  • Page 10 SUPERSERVER 1027R-N3RF USER'S MANUAL Notes...

  • Page 11: Chapter 1 Introduction

    Overview Supermicro's SuperServer 1027R-N3RF is a dual processor, 1U rackmount server. The 1027R-N3RF is a high-end server comprised of two main subsystems: the SC116TS-R700WBP 1U server chassis and the X9DRW-3F dual processor serverboard. Please refer to our web site for information on operating systems that have been certifi...

  • Page 12: Serverboard Features

    Serverboard Features At the heart of the SuperServer 1027R-N3RF lies the X9DRW-3F, a dual processor serverboard based on the Intel PCH C606 chipset. Below are the main features of the X9DRW-3F. (See Figure 1-1 for a block diagram of the chipset).

  • Page 13: Onboard Controllers/Ports

    SC116TS-R700WBP chassis. System Power When confi gured as a SuperServer 1027R-N3RF, the SC116TS-R700WBP chassis includes two redundant hot-swappable 700 Watt power supplies. In the unlikely event your power supply fails, replacement is simple and can be done without tools.

  • Page 14: Front Control Panel

    SUPERSERVER 1027R-N3RF USER'S MANUAL Front Control Panel The SC116TS-R700WBP control panel provides important system monitoring and control information. LEDs indicate power on, network activity, hard disk drive activity and a UID (Universal Information) LED. Also present are a main power button, a system reset button and a UID button.
  • Page 15 Chapter 1: Introduction Figure 1-1. Intel PCH C606 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. Right Slot PCIE 3.0x16 PE2 PE1 CPU Rear Socket 01 PROCESSOR CPU Front Socket 00 PROCESSOR BIOS P0PE3...

  • Page 16: Contacting Supermicro

    SUPERSERVER 1027R-N3RF USER'S MANUAL Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 17: Chapter 2 Server Installation

    If the server itself shows damage you should fi le a damage claim with the carrier who delivered it. Decide on a suitable location for the rack unit that will hold the 1027R-N3RF. It should be situated in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and electromagnetic fi...

  • Page 18: Choosing A Setup Location

    SUPERSERVER 1027R-N3RF USER'S MANUAL Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for suffi cient airfl ow and ease in servicing.This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like).

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation • Install the heaviest server components on the bottom of the rack fi rst, and then work up. • Use a regulating uninterruptible power supply (UPS) to protect the server from power surges, voltage spikes and to keep your system operating in case of a power failure.

  • Page 20: Circuit Overloading

    SUPERSERVER 1027R-N3RF USER'S MANUAL Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 21: Installing The System Into A Rack

    Chapter 2: Server Installation Installing the System into a Rack This section provides information on installing the SC116 chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.

  • Page 22: Inner Rails

    SUPERSERVER 1027R-N3RF USER'S MANUAL Inner Rails The SC116 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack. Attach the inner rail extension to stabilize the chassis within the rack.

  • Page 23: Outer Rails

    Chapter 2: Server Installation Outer Rails Installing the Outer Rails to the Rack (Figures 2-3 and 2-4) 1. Attach the shorter outer rail to the outside of the longer outer rail. You must align the pins with the slides. Both bracket ends must face the same direction. 2.
  • Page 24 SUPERSERVER 1027R-N3RF USER'S MANUAL Figure 2-4. Installing the Outer Rails to the Rack...
  • Page 25 Chapter 2: Server Installation Installing the Chassis into a Rack (Figure 2-5) 1. Confi rm that chassis includes the inner rails and inner rail extensions. Alsoconfi rm that the outer rails are installed on the rack. 2. Align the chassis inner rails with the front of the out rails on the rack. 3.

  • Page 26: Checking The Serverboard Setup

    SUPERSERVER 1027R-N3RF USER'S MANUAL Checking the Serverboard Setup After you install the 1027R-N3RF in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Removing the Chassis Cover (Figure 2-7) 1.

  • Page 27: Checking The Drive Bay Setup

    Chapter 2: Server Installation 4. Make sure all power and data cables are properly connected and not blocking the chassis airfl ow. See Chapter 5 for details on cable connections. Also, check the air seals for damage. The air seals are located under the blower fan and beneath the frame cross section that separates the drive bay area from the serverboard area of the chassis.
  • Page 28 SUPERSERVER 1027R-N3RF USER'S MANUAL Notes 2-12...

  • Page 29: Chapter 3 System Interface

    There are several LEDs on the control panel and on the drive carriers that provide system and component status for the 1027R-N3RF server. This chapter explains the meanings of all LED indicators and the appropriate responses that need to be taken.

  • Page 30: Uid

    SUPERSERVER 1027R-N3RF USER'S MANUAL Depressing the UID (unit identifi er) button illuminates an LED on both the front and rear of the chassis for easy system location in large stack confi gurations. The LED will remain on until the button is pushed a second time. Another UID button on the rear of the chassis serves the same function.

  • Page 31: Control Panel Leds

    Chapter 3: System Interface Control Panel LEDs The control panel located on the front of the SC116TS-R700WBP chassis has fi ve LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 32: Power

    SUPERSERVER 1027R-N3RF USER'S MANUAL Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Hard Drive Carrier LEDs Each hard drive carrier has two LEDs. • Green: When illuminated, the green LED on the front of the drive carrier indicates drive activity.

  • Page 33: Chapter 4 Standardized Warning Statements For Ac Systems

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 34 SUPERSERVER 1027R-N3RF USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 35 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...

  • Page 36: Installation Instructions

    SUPERSERVER 1027R-N3RF USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 37: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. 警告 此产品的短路(过载电流)保护由建筑物的供电系统提供,确保短路保护设备的额定电 流不大于250V,20A。 警告 此產品的短路(過載電流)保護由建築物的供電系統提供,確保短路保護設備的額定電 流不大於250V,20A。...

  • Page 38: Power Disconnection Warning

    SUPERSERVER 1027R-N3RF USER'S MANUAL ‫ﻓﻲ‬ ‫ﺍﻟﺘﻲ ﺗﻢ ﺗﺜﺒﻴﺘﻬﺎ‬ ‫ﻣﻦ ﺍﻟﺪﻭﺍﺋﺮﺍﻟﻘﺼﻴﺮﺓ‬ ‫ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﻳﻌﺘﻤﺪ ﻋﻠﻰ‬ ‫ﻫﺬﺍ ﺍﻟﻤﻨﺘﺞ‬ ‫ﺍﻟﻤﺒﻨﻰ‬ ‫ﺃﻛﺜﺮ ﻣﻦ‬ ‫ﻟﻴﺲ‬ ‫ﻮﻗﺎﺋﻲ‬ ‫ﺍﻟ‬ ‫ﺍﻟﺠﻬﺎﺯ‬ ‫ﺗﻘﻴﻴﻢ‬ ‫ﺃﻥ‬ ‫ﺗﺄﻛﺪ ﻣﻦ‬ 20A, 250V Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie.
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 40: Equipment Installation

    SUPERSERVER 1027R-N3RF USER'S MANUAL Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi ziertem Personal gestattet werden.

  • Page 41: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 42: Battery Handling

    SUPERSERVER 1027R-N3RF USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬...
  • Page 43 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 44: Redundant Power Supplies

    SUPERSERVER 1027R-N3RF USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 45: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ Waarschuwing Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken. Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is...

  • Page 46: Comply With Local And National Electrical Codes

    SUPERSERVER 1027R-N3RF USER'S MANUAL Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬...

  • Page 47: Product Disposal

    Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...

  • Page 48: Easy Swap Fan Warning

    SUPERSERVER 1027R-N3RF USER'S MANUAL Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
  • Page 49 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他 物品太靠近风扇 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 50: Power Cable And Ac Adapter

    SUPERSERVER 1027R-N3RF USER'S MANUAL Waarschuwing Het is mogelijk dat de ventilator nog draait tijdens het verwijderen van het ventilatorsamenstel uit het chassis. Houd uw vingers, schroevendraaiers en eventuele andere voorwerpen uit de buurt van de openingen in de ventilatorbehuizing. Power Cable and AC Adapter...
  • Page 51 Chapter 4: Warning Statements for AC Systems ¡Advertencia! Al instalar el producto, utilice los cables de conexión previstos o designados, los cables y adaptadores de CA. La utilización de otros cables y adaptadores podría ocasionar un mal funcionamiento o un incendio. Aparatos Eléctricos y la Ley de Seguridad del Material prohíbe el uso de UL o CSA cables certifi...
  • Page 52 SUPERSERVER 1027R-N3RF USER'S MANUAL Waarschuwing Bij het installeren van het product, gebruik de meegeleverde of aangewezen kabels, stroomkabels en adapters. Het gebruik van andere kabels en adapters kan leiden tot een storing of een brand. Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertifi...

  • Page 53: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X9DRW-3F serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.

  • Page 54: Processor And Heatsink Installation

    SUPERSERVER 1027R-N3RF USER'S MANUAL Processor and Heatsink Installation Warning! When handling the processor package, avoid placing direct pressure on the label area. Warning! Always connect the power cord last, and always remove it before adding, removing or changing any hardware components. Make sure that you install the processor into the CPU socket before you install the CPU heatsink.
  • Page 55 Chapter 5: Advanced Serverboard Setup 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Press down on Load the Lever Pull lever away labeled 'Close 1st' from the socket 3.
  • Page 56 SUPERSERVER 1027R-N3RF USER'S MANUAL 5. Use your thumb and index fi nger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 6. Once they are aligned, carefully lower the CPU straight down into the socket.
  • Page 57 Chapter 5: Advanced Serverboard Setup 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 8. Close the load plate with the CPU inside the socket. Lock the lever labeled 'Close 1st' fi...

  • Page 58: Installing A Passive Cpu Heatsink

    SUPERSERVER 1027R-N3RF USER'S MANUAL Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the serverboard and the Heatsink Bracket underneath.

  • Page 59: Removing The Heatsink

    Chapter 5: Advanced Serverboard Setup Removing the Heatsink Caution: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket. 1.

  • Page 60: Connecting Power Cables

    SUPERSERVER 1027R-N3RF USER'S MANUAL Connecting Power Cables The X9DRW-3F has a 24-pin primary power supply connector designated "JPW1" for connection to the ATX power supply. Connect the appropriate connector from the power supply to JPW1 to supply power to the serverboard. See the Connector Defi...

  • Page 61: I/O Ports

    Chapter 5: Advanced Serverboard Setup I/O Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See Figure 5-3 below for the colors and locations of the various I/O ports. Figure 5-3. Rear Panel I/O Ports Rear I/O Ports 1.

  • Page 62: Installing Memory

    SUPERSERVER 1027R-N3RF USER'S MANUAL Installing Memory Caution! Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support T h e X 9 D R W - 3 F s u p p o r t s u p t o 5 1 2 G B o f r e g i s t e r e d E C C 1GB, 2GB, 4GB, 8GB, 16GB and 32GB size SDRAM in sixteen (16) DIMM slots of up to DDR3 1600/1333/1066/800 MHz speed.
  • Page 63 Chapter 5: Advanced Serverboard Setup Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules CPU 1 DIMMA1 DIMMA2 DIMMB1 DIMMB2 DIMMC1 DIMMC2 DIMMD1 DIMMD2 CPU2 DIMME1 DIMME2 DIMMF1 DIMMF2 DIMMG1 DIMMG2 DIMMH1 DIMMH2 Processor and Memory Module Population Number of CPU and Memory Population Confi...

  • Page 64: Adding Pci Expansion Cards

    SUPERSERVER 1027R-N3RF USER'S MANUAL LRDIMM Support on the Intel E5-2600 Series Processor Platform DIMMs Populated LRDIMM Type POR Speeds (in Ranks per DIMM per DDR Channel (Load Reduced MHz) (Any Combination) DIMM) LR ECC DDR3 1066, 1333 LR ECC DDR3...

  • Page 65: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-5. X9DRW-3F Serverboard Layout (not drawn to scale) COM1 USB0/1 JUIDB CTRL LAN1 LAN2 USB2/3 JPW4 IPMI-LAN CPU2 COM2 X9DRW-3F/iF Rev.1.02 CTRL JPW3 JI2C1 JVRM_I2C1 JPG1 BIOS JVRM_I2C2 CPU1 JPW2 JBT1 JBAT1 SATA/ SCU0~3 SATA/SCU4~7...

  • Page 66: X9Drw-3F Quick Reference

    SUPERSERVER 1027R-N3RF USER'S MANUAL X9DRW-3F Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Chapter 3 JI2C1/JI2C2 SMB to PCI-E Slots Open (Normal) JPB1 BMC Enable Pins 1-2 (Enabled) JPG1 VGA Enable Pins 1-2 (Enabled) JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)
  • Page 67 Chapter 5: Advanced Serverboard Setup Connector Description COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header FAN1~4,FANA, FANB CPU/System Fan Headers I-SATA 0~5 Intel PCH SATA Connectors 0~5 JBAT1 Onboard Battery (See Chpt. 4 for Used Battery Disposal) Speaker/Power LED Connector (Pins 1~3: PWR LED, Pins 6~7: Onboard Buzzer/Pins 4~7: External Speaker) Front Panel Control Header JIPMB1...

  • Page 68: Connector Defi Nitions

    SUPERSERVER 1027R-N3RF USER'S MANUAL Warning! To prevent damage to the power supply or serverboard, please use a power supply that contains a 24-pin, two 8-pin and one 4-pin power connectors. Be sure to connect these power supply connectors to the 24-pin power connector (JPW1), the two 8-pin power connectors (JPW2, JPW3) and the one 4-pin power connector (JPW4) on the serverboard.
  • Page 69 Chapter 5: Advanced Serverboard Setup PW_ON Connector Power Button Pin Defi nitions The Power Button connection is (JF1) located on pins 1 and 2 of JF1. Pin# Defi nition Momentarily contacting both pins will PW_ON power on/off the system. This button Ground can also be confi...
  • Page 70 SUPERSERVER 1027R-N3RF USER'S MANUAL NIC1 (LAN1) LED NIC1 LED Pin Defi nitions (JF1) The NIC (Network Interface Controller) Pin# Defi nition LED connections for GLAN port 1 are NIC 2 Activity LED located on pins 11 and 12 of JF1, and...
  • Page 71 Chapter 5: Advanced Serverboard Setup Universal Serial Bus (USB) FP USB (4/5) Pin Defi nitions Four Universal Serial Bus ports (USB USB 4, 8,10, 6, 7 USB 5, 9, 11 0/1, 2/3) are located on the I/O back Pin # Defi nition Pin # Defi...
  • Page 72 SUPERSERVER 1027R-N3RF USER'S MANUAL Serial Ports Serial Port Pin Defi nitions (COM1/COM2) Two COM connections (COM1 & Pin # Defi nition Pin # Defi nition COM2) are located on the serverboard. COM1 is located on the Backplane I/O panel. COM2, located next to Front Accessible USB 4/5, is used to provide front access serial support.
  • Page 73 Chapter 5: Advanced Serverboard Setup Unit Identifi er Switch UID Switch A Unit Identifier (UID) Switch and Pin# Defi nition two LED Indicators are located on Ground the serverboard. The UID Switch is Ground located next to the VGA port. The Button In Rear UID LED (LED3) is located next Ground...
  • Page 74 SUPERSERVER 1027R-N3RF USER'S MANUAL Overheat LED/Fan Fail Overheat LED Pin Defi nitions The JOH1 header is used to connect (JOH1) an LED indicator to provide warnings Pin# Defi nition of chassis overheating and fan failure. This LED will blink when a fan failure OH Active occurs.
  • Page 75 Chapter 5: Advanced Serverboard Setup IPMB IPMB Header Pin Defi nitions A System Management Bus header for (JIPMB1) IPMI 2.0 is located at JIPMB1. Connect Pin# Defi nition the appropriate cable here to use the Data IPMB I C connection on your system. Ground Clock No Connection...
  • Page 76 SUPERSERVER 1027R-N3RF USER'S MANUAL Legacy Wake-On-LAN Header Legacy Wake- (JSTBY) On-LAN Header Pin Defi nitions The onboard LAN por ts do not need (JSTBY) a WOL header to support their Wake- Pin# Defi nition On-LAN function. Instead, the legacy +5V Standby...

  • Page 77: Jumper Settings

    Chapter 5: Advanced Serverboard Setup Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the Jumper serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two Setting pins to change the function of the connector.
  • Page 78 SUPERSERVER 1027R-N3RF USER'S MANUAL LAN Enable/Disable LAN Enable/Disable Jumper Settings (JPL1) JPL1 enables or disables the GLAN Jumper Setting Defi nition Port1/GLAN Port2 on the serverboard. Pins 1-2 Enabled (default) See the table on the right for jumper Pins 2-3 Disabled settings.

  • Page 79: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup 5-10 Onboard Indicators GLAN LEDs GLAN LED Activity Link Speed The LAN 1/2 ports are located on the IO Backplane. Each Ethernet LAN port has two LEDs. The Yellow LED on the GLAN Activity Indicator right indicates activity.

  • Page 80: 5-11 Sata Drive Connections

    SUPERSERVER 1027R-N3RF USER'S MANUAL Rear UID LED UID LED Status The rear UID LED is located at LED3 Color/State Status on the rear of the serverboard. This Blue: On Unit Identifi ed LED is used in conjunction with the Blue: On Unit Identifi...

  • Page 81: 5-12 Installing Drivers

    Chapter 5: Advanced Serverboard Setup 5-12 Installing Drivers The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO fi...
  • Page 82 SuperDoctor III, as the SuperDoctor III settings override the BIOS settings. To set the BIOS temperature threshold settings again, you would fi rst need to uninstall SuperDoctor III. Figure 5-7. Supero Doctor III Interface Display Screen (Health Information) 5-30...

  • Page 83: Superdoctor Iii

    Chapter 5: Advanced Serverboard Setup Figure 5-8. Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we recommend that you use the SuperoDoctor II application instead.

  • Page 84: 5-13 Serverboard Battery

    SUPERSERVER 1027R-N3RF USER'S MANUAL 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-9). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).

  • Page 85: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC116TS-R700WBP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step.

  • Page 86: Control Panel

    SUPERSERVER 1027R-N3RF USER'S MANUAL Figure 6-1. Chassis: Front and Rear Views Control Panel Hot-Swap Drive Bays (10) IPMI Port PCI Expansion Slots (w/ Riser Cards) Power Supplies COM1 Port USB Ports Ethernet Ports VGA Port Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications.

  • Page 87: System Fans

    Chapter 6: Advanced Chassis Setup System Fans Five heavy-duty fans provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the chassis' internal temperature. The SC116 chassis contains counter-rotating fans. Each fan unit is actually made up of two fans joined back-to-back, which rotate in opposite directions.

  • Page 88: System Fan Failure

    SUPERSERVER 1027R-N3RF USER'S MANUAL System Fan Failure Fan speed is controlled by system temperature via IPMI software. If a fan fails, the remaining fans will ramp up to full speed. Replace any failed fan at your earliest convenience with the same type and model (the system can continue to run with a failed fan).

  • Page 89: Installing The Air Shroud

    Chapter 6: Advanced Chassis Setup Installing the Air Shroud Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC116 chassis air shroud does not require screws to set up. Air Shroud Installation (Figure 6-4) 1. Position the air shroud in alignment with the CPU, memory card and fan locations.

  • Page 90: Drive Bay Installation/Removal

    SUPERSERVER 1027R-N3RF USER'S MANUAL Drive Bay Installation/Removal Accessing the Drive Bays Hard Drives: Because of their hotswap capability, you do not need to access the inside of the chassis or power down the system to install or replace hard drives.
  • Page 91 Chapter 6: Advanced Chassis Setup Removing a Hard Drive (Figure 6-6) 1. To remove a carrier, push the release button located beside the drive LEDs. 2. Swing the handle fully out and use it to pull the unit straight out. Note: Your operating system must have RAID support to enable the hot-plug capability of the hard drives.

  • Page 92: Expansion Card Setup

    SUPERSERVER 1027R-N3RF USER'S MANUAL Warning: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/fi les/ storage/SAS-CompList.pdf Expansion Card Setup SC116 chassis includes PCI slots for expansion cards. Some models (such as SC116TS-R700WBP) include two full height an one low profi...

  • Page 93: Power Supply

    Chapter 6: Advanced Chassis Setup 11. Secure the expanion card by closing the PCI slot lever. 12. Connect cables to the expansion card if necessary. Figure 6-8: Installing an Expansion Card Riser Bracket Card Secure the Bracket to the Chassis Power Supply The SC116 chassis comes equipped with two redundant 700 Watt power supplies.
  • Page 94 SUPERSERVER 1027R-N3RF USER'S MANUAL Replacing the Power Supply (Figure 6-9) 1. Push the release tab (on the back of the power supply) as illustrated. 2. Pull the power supply out using the handle provided. 3. Replace the failed power module with the same model.

  • Page 95: Chapter 7 Bios

    BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the SuperServer 1027R-N3RF. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.

  • Page 96: System Time/System Date

    SUPERSERVER 1027R-N3RF USER'S MANUAL System Time/System Date You can edit this fi eld to change the system time and date. Highlight System Time or System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fi elds. The date must be entered in DAY/MM/DD/YYYY format.
  • Page 97 Chapter 7: BIOS Power Confi guration Watch Dog Function If enabled, the Watch Dog timer will allow the system to reboot when it is inactive for more than 5 minutes. The options are Enabled and Disabled. Power Button Function If this feature is set to Instant Off, the system will power off immediately as soon as the user presses the power button.
  • Page 98 SUPERSERVER 1027R-N3RF USER'S MANUAL  Socket 1 CPU Information/Socket 2 CPU Information This submenu displays the following information regarding the CPUs installed in Socket 1/ Socket 2. • Type of CPU • CPU Signature • Microcode Patch • CPU Stepping •...
  • Page 99 Chapter 7: BIOS Limit CPUID Maximum This feature allows the user to set the maximum CPU ID value. Enable this function to boot the legacy operating systems that cannot support processors with extended CPUID functions. The options are Disabled (for the Windows OS), and Enabled. Execute Disable Bit Capability (Available if supported by the OS &...
  • Page 100 SUPERSERVER 1027R-N3RF USER'S MANUAL Note: If there is any change to this setting, you will need to power off and restart the system for the change to take effect. Please refer to Intel’s website for detailed information.) CPU Power Management Confi guration This submenu allows the user to confi...
  • Page 101 Chapter 7: BIOS CPU C7 Report (Available when Power Technology is set to Custom) Select Enabled to allow the BIOS to report the CPU C7 State (ACPI C400) to the operating system. CPU C7 State is a processor-specifi c low C-State. The options are Enabled and Disabled.

  • Page 102: North Bridge

    SUPERSERVER 1027R-N3RF USER'S MANUAL Chipset Confi guration North Bridge This feature allows the user to confi gure the settings for the Intel North Bridge. Integrated IO Confi guration Intel VT-d Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to the VWM (Virtual Working Memory) through the DMAR ACPI Tables.
  • Page 103 Chapter 7: BIOS QPI Confi guration Current QPI Link This item displays the current status of the QPI Link. Current QPI Frequency This item displays the frequency of the QPI Link. Isoc Select Enabled to enable Isochronous support to meet QoS (Quality of Service) requirements.

  • Page 104: Dimm Information

    SUPERSERVER 1027R-N3RF USER'S MANUAL DIMM Information The status of the memory modules specifi ed below will be displayed as detected by the BIOS. CPU Socket 1 DIMM Information P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1/P1-DIMMA2/P1-DIMMB2/ P1-DIMMC2/P1-DIMMD2 CPU Socket 2 DIMM Information P2-DIMME1/P2-DIMMF1/P2-DIMMG1/P2-DIMMH1/P2-DIMME2/P2-DIMMF2/ P2-DIMMG2/P2-DIMMH2 Memory Mode When Independent is selected, all DIMMs are available to the operating system.
  • Page 105 Chapter 7: BIOS Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source). When this item is set to Enabled, the IO hub will read and write back one cache line every 16K cycles, if there is no delay caused by internal processing.
  • Page 106 SUPERSERVER 1027R-N3RF USER'S MANUAL South Bridge Confi guration This feature allows the user to confi gure the settings for the Intel PCH chip. PCH Information This feature displays the following PCH information. Name: This item displays the name of the PCH chip.
  • Page 107 Chapter 7: BIOS SATA Confi guration When this submenu is selected, the AMI BIOS automatically detects the presence of IDE or SATA devices and displays the following items. SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port as detected by the BIOS. SATA Mode Use this feature to confi...
  • Page 108 SUPERSERVER 1027R-N3RF USER'S MANUAL RAID Mode The following items are displayed when RAID Mode is selected: Port 0~5 Hot Plug Select Enabled to enable hot-plug support for the particular port. The options are Enabled and Disabled. SCU (Storage Control Unit) Confi guration Storage Controller Unit Select Enabled to enable PCH SCU storage devices.
  • Page 109 Chapter 7: BIOS SERR# Generation Select Enabled to allow a PCI device to generate an SERR number for a PCI Bus Signal Error Event. The options are Enabled and Disabled. Maximum Payload Select Auto to allow the system BIOS to automatically set the maximum payload value for a PCI-E device to enhance system performance.
  • Page 110 SUPERSERVER 1027R-N3RF USER'S MANUAL Network Stack Select Enabled enable PXE (Preboot Execution Environment) or UEFI (Unifi ed Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. Super IO Confi guration Super IO Chip: This item displays the Super IO chip used in the serverboard.

  • Page 111: Serial Port Console Redirection

    Chapter 7: BIOS Serial Port 2 Attribute Use this feature to select the attribute for serial port 2. The options are SOL (Serial On LAN), and COM. Serial Port Console Redirection • COM 1 and SOL/COM 2 These two submenus allow the user to confi gure the following Console Redirection settings for a COM Port selected by the user.
  • Page 112 SUPERSERVER 1027R-N3RF USER'S MANUAL Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 113 Chapter 7: BIOS  Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) The submenu allows the user to confi gure Console Redirection settings to support Out-of-Band Serial Port management. The options are Enabled and Disabled. Console Redirection Settings The feature allows the user to confi gure console redirection settings for a local machine to communicate with a remote server.

  • Page 114: Tpm Enable Status

    SUPERSERVER 1027R-N3RF USER'S MANUAL TPM State Select Enabled to enable TPM security settings to improve data integrity and network security. The options are Disabled and Enabled. Pending Operation: This item displays the status of a pending operation. Current Status Information: This item displays the information regarding the current TPM status.

  • Page 115: Discard Changes And Exit

    Chapter 7: BIOS TPM Support: Trusted Platform support TPM State: Trusted Platform state Intel ME Subsystem Confi guration This feature displays the following ME Subsystem Confi guration settings. • ME BIOS Interface Version • ME Version iSCSI Confi guration: This item displays iSCSI confi guration information: iSCSI Initiation Name: This item displays the name of the iSCSI Initiator, which is a unique name used in the world.

  • Page 116: Event Logs

    SUPERSERVER 1027R-N3RF USER'S MANUAL NIC Confi guration Link Speed This item allows the user to set the link speed for your network connections. The Options are AutoNeg (Auto Negotiation), 10 Mbps Half, 10 Mbps Full, 100 Mbps Half, and 10 Mbps Full.
  • Page 117 Chapter 7: BIOS Runtime Error Logging Support Select Enabled to support Runtime Error Logging. The options are Enabled and Disabled. Memory Correctable Error Threshold This feature allows the user to enter the threshold value for correctable memory errors. The default setting is 10. PCI Error Logging Support Select Enabled to support error event logging for PCI slots.

  • Page 118: Ipmi

    SUPERSERVER 1027R-N3RF USER'S MANUAL View System Event Log This item allows the user to view the event in the system event log. Select this item and press <Enter> to view the status of an event in the log as shown below:...
  • Page 119 Chapter 7: BIOS Note: After making changes on a setting, be sure to reboot the system for the changes to take effect.  BMC Network Confi guration LAN Channel 1: This feature allows the user to confi gure the settings for LAN1 Port. Update IPMI LAN Confi...

  • Page 120: Boot

    SUPERSERVER 1027R-N3RF USER'S MANUAL Boot This submenu allows the user to confi gure the following boot settings for the system. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot. The options are Enabled, Disabled and Auto.

  • Page 121: Security

    Chapter 7: BIOS Security This menu allows the user to confi gure the following security settings for the system. Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.
  • Page 122 SUPERSERVER 1027R-N3RF USER'S MANUAL Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.

  • Page 123: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 124 SUPERSERVER 1027R-N3RF USER'S MANUAL Notes...

  • Page 125: Appendix B System Specifi Cations

    Appendix B: System Specifi cations Appendix B System Specifi cations Processors Dual Intel E5-2600 Series series (Socket R LGA2011 type) processors Note: You must install at least two processors for full functions to be supported. Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel PCH C606 chipset BIOS...
  • Page 126 SUPERSERVER 1027R-N3RF USER'S MANUAL Chassis SC116 (1U rackmount form factor) Dimensions: (WxHxD) 17.2 x 1.7 x 23.5 in. (437 x 43 x 597 mm) Weight Gross (Bare Bone): 33 lbs. (15 kg.) System Cooling Five (5) 4-cm system easy swap cooling fans...
  • Page 127 Appendix B: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 128 SUPERSERVER 1027R-N3RF USER'S MANUAL (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...

Table of Contents
