Battery Installation - Oceanic DATA PLUS Owner's Manual

WARNING: DO NOT attempt to remove the outer case ring (Fig.
75a). Doing so may cause a dangerous malfunction, resulting in
possible injury or death. Indication of tampering with the ring
will void the warranty.
• Turn the unit over to drop out the two 3 volt lithium batteries. Discard,
regardless of age or amount of use.
• Closely check the metal contacts inside the battery compartment for any
signs of stress (bending or breakage), and for any signs of corrosion indicat-
ing entrance of moisture into the unit. If found, return your DataPlus to an
Authorized Oceanic Dealer, and DO NOT attempt to use the unit until it
has received factory service.

BATTERY INSTALLATION

• Remove and check the battery hatch as previously described.
• If necessary to replace the battery hatch o-ring, lightly lubricate it with
silicone grease and stretch it slightly to work it down over the slotted top of
the hatch, DO NOT roll it over the threads.
• Install two new 3 volt lithium batteries (Duracell
23-162, Maxell ® CR2032, Panasonic
compartment with the positive (+) side facing up (out of the battery com-
partment), with one directly on top of the other (Fig. 76). Avoid touching
either the battery contacts or the flat surfaces of the batteries, as skin oil
®
DL2032, Radio Shack
® CR2032, or equivalent) into the battery
DataPlus
a
USE
COIN ONLY
Fig. 75 - Outer Case Ring
(+)
(-)
(+)
(-)
Btm
®
Top
Fig. 76 - Installing Batteries
Battery
Hatch
Batteries
71
