GAUGE MODE

Underwater the Gauge Mode is a continuation of the Immediate Violation Mode
that turns the DataPlus into a digital instrument without any decompression or
oxygen monitoring functions (Fig. 64).
After surfacing, Gauge Mode does not provide the Time to Fly, FO2, PO2, and
PDPS features. During the first 12 hour period, the full TLBG and O2 bar
graphs will flash and the dive number, and Surface mode icon will be displayed
with a Surface Time of '0:00' (Fig. 65). During the second 12 hour period a single
dash will be displayed with a countdown timer beginning at 12:00 to inform you
of the time remaining before normal DataPlus operation can resume with full
features. If a dive is made during the 24 hour period that the DataPlus is in the
Gauge Mode, only depth and elapsed dive time information will be displayed.

PERMANENT VIOLATION

Entering the Immediate Violation Mode, then Gauge Mode, will result in loss of
all DataPlus decompression and oxygen monitoring and calculating functions for
24 hours after that dive. This condition is considered a Permanent Violation.
Responsible
DataPlus
FT
FT
MAX
DATA
PLUS
GLO
Fig. 64 - Gauge Mode
(underwater)
DATA
PLUS
GLO
Fig. 65 - Gauge Mode
(surface)
55
