REGULATOR ATTACHMENT

If you have purchased the DataPlus in a console version, you will need to have it
attached to your regulator first stage by an Authorized Oceanic Dealer.

ACTIVATING THE DISPLAY

You activate the DataPlus by pressing and releasing the control button located
below the display (Fig. 1a). Depressing and holding the control button for 8
seconds will allow you to enter the External Access Mode used when you down-
load (copy) dive data from the DataPlus to the OceanLink™ PC software logging
program that is available separately. Depressing the button during the Dive
Mode will activate the unit's temperature and Oceanglo ® backlight features.
R3
After a diagnostic check that lasts several seconds, the DataPlus advances
through a sequence of displays, called the Surface Sequence, that will repeat
continually until a dive is made, or until the unit shuts off automatically. First
to appear will be Surface Mode, followed by FO2, then PO2 (if FO2 is 'set'), and
DATA
PLUS b
GLO
the Pre Dive Planning Sequence. After a dive is made, Time to Fly will appear
prior to FO2. These displays will all be explained as you read through this guide.
a
The 'pre dive' Surface Mode identified by the Surface Mode icon (Fig. 1b) and
Fig. 1 - Surface Mode
the number "0" indicating that no dive has been made since activation. The
