Surface Time display will start counting up from 0:00. If no dive is made within
2 hours (2:00) after activation, the unit will automatically shut off.
After displaying the Surface Mode for several seconds, the DataPlus advances to
the display FO2 and Air for 5 seconds (Fig. 2) during which time percentage
O2 for that dive's nitrox mix can be programmed (set) by pressing and holding
the control button. If you set FO2 for a value other than 'Air', the DataPlus will
advance to the PO2 display (Fig. 3) that shows the Maximum Depth that can be
achieved with an oxygen partial pressure of 1.60 BAR for the FO2 value set. If
FO2 is set for 'Air', the PO2 display will not appear.
Next the DataPlus advances to a Plan Mode (Fig. 4) referred to as the Pre Dive
Planning Sequence or PDPS signified by the PDPS icon (Fig. 4a). The PDPS
displays a sequence of depths from 30 to 160 feet (9 to 48 meters) in 10 foot (3
meter) increments. Each depth is displayed with its corresponding available
adjusted no decompression limit for 3 seconds.
After completing the PDPS, the Surface Sequence will repeat over and over
again until you dive.
WARNING: The DataPlus must be manually activated and be in
the Surface Mode or PDPS Mode prior to start of a dive. The
unit will not activate automatically by immersion in water.
DataPlus
DATA
PLUS
GLO
Fig. 2 - FO2
FT
MAX
DATA
PLUS
GLO
Fig. 3 - PO2
FT
DATA
PLUS
GLO
a
Fig. 4 - PDPS
5
