Oceanic DATA PLUS Owner's Manual page 30

®
segments of the LCD include - FO2 set point value, 'EA' (External Access), and
'FLY' (during the first 12 hours).
A second time display, located in the center right portion of the LCD (Fig. 23b,
page 19), indicates Elapsed Dive Time, or Decompression Stop Time required
(Fig.24b) for the current stop ceiling indicated, as identified by the Elapsed Dive
Time and Ceiling Stop icons, respectively. Other displays that utilize these
segments of the LCD include - 'FO2', 'PO2', 'O2', and time to fly minutes (during
the first 12 hours).
Note that the maximum value of Elapsed Dive Time that will be displayed is
b
1:59 (hr:min). When Elapsed Dive Time exceeds 1 hour and 59 minutes, the
- -
display will show 1: for the remainder of that dive and in the log for that dive.
a
FT
Time displays are shown in hour:minute format (i.e. 1:06 represents one hour
FT
and six minutes, not 106 minutes!). The colon that separates hours and minutes
blinks once per second when the display is indicating real time such as elapsed
Surface Time or Dive (bottom) Time. Dive Time Available, No Decompression
DATA
Dive Time Remaining, Total Ascent Time required, or Time to Fly are calculated
PLUS
GLO
projections of time and use a solid (non-blinking) colon to indicate that they are
counting down, rather than counting up.
Fig. 24 - Decompression Stop
Depth / Time
20
