2.2.1.2 Push-to-Talk V2 Speaker (with PoE Injector) to a 802.3af Compliant PoE Switch

Figure

separately). A PoE Injector is a power supply solution for those who have a standard Non PoE

Switch.

Operations Guide

2-2, if a PoE switch is not available, you will need a PoE Injector, part #010867A (ordered

Figure 2-2. Push-to-Talk V2 Speaker (with PoE Injector) to a Non PoE Switch

Non PoE Switch

PoE Injector (Part #010867A)

Cat 5 Ethernet cable

930468A

Installing the VoIP V2 Speaker

Connect Power to the Speaker

VoIP V2 Speaker
