Product Specifications - CyberData 11180 Operation Manual

1.6 Product Specifications

Category
Audio sensitivity
Audio output
Operating temperature
Ethernet port baud rate
Protocol
Power Input (J1)
a
or Auxiliary Power Input
(Terminal Block J10)
Payload types
Regulatory compliance
Warranty
Dimensions
Weight
Part number
a.Auxiliary power input for use when PoE power is not available. 12 VDC @ 1A. Do not use auxiliary power input
when speaker J1 is connected to a PoE power source.
Operations Guide
Table 1-1. Product Specifications
Specification
96dB/1W/1M S.P. Level
10 Watts Peak Power
-30 to 55 C (-22 to 131 F)
10/100 Mbps
SIP RFC 3261 Compatible
PoE 802.3af (as per IEEE 802.3af standard from a UL-listed, LPS-rated limited power source)
44-57 VDC (48 VDC nominal) at 350mA
12 VDC at 1A (from a UL-listed, LPS-rated power supply)
G711, A-law and µ-law
FCC Class B, CE
2 years limited
9" x 2.4"
2.8 lbs./shipping weight of 3.8 lbs.
(1.3 kg/shipping weight of 1.7 kg)
011180, RAL 9002, Gray White, Standard Color
011181, RAL 9003, Signal White, Optional Color
930468A
Product Overview
Product Specifications
CyberData Corporation
4
