2.2.2 Loudspeaker Amplifier NEMA Box Components
Figure 2-4
Operations Guide
shows all of the NEMA box components of the loudspeaker amplifier.
Figure 2-4. Loudspeaker Amplifier Components—AC powered
930376B
Installing the VoIP V2 Loudspeaker Amplifier
Loudspeaker Amplifier Setup
DIP Switches
RTFM Switch
Ethernet Connection
Ethernet Hub
LEDs
Volume
Speaker Connection
Injector
AC power
