6.
Click the Page Setup tab to display the Page Setup sheet.
7.
A
In Page Size, click the size of the original as specified in the application. In this case, click ISO A3.
8.
Select and click a roll paper in the
9.
Select the width of the loaded roll in the
10.
Specify additional printing conditions.
For details on available printing conditions, see " Printer Driver Settings (Windows)
11.
Confirm the print settings and print as desired.
Note
• For tips on confirming print settings, see " Confirming Print Settings (Windows)
• You can conserve roll paper by configuring settings suitable for the document.
For details on how to conserve paper and print, refer to " Conserving Roll Paper by Rotating Origi-
nals 90 Degrees (Windows)

Printing Line Drawings and Text (Mac OS X)

This topic describes how to print line drawings based on the following example.
• Document: CAD drawing
• Page size: A3 (297.0 × 420.0 mm [11.7 × 16.5 in])
• Paper: Roll
• Paper type: Plain Paper
iPF6300S
Enhanced Printing Options
L
Paper Source list.
M
Roll Paper Width list—in this case, ISO A2/A3 Roll (420.0mm).
".
→P.172
> Printing CAD Drawings
"
→P.202
→P.207
Printing Line Drawings and Text (Mac OS X)
>
2
"
49
