INSTALLATION

Remove all packaging before positioning the
machine.
Refer also to the separate assembly instructions
sheet.
Positioning
If possible, position the machine next to a water tap
and a drain.
This dishwasher is designed to be fitted under a
kitchen counter or sink only and can not be converted
to mobile or freestanding.
Water supply connections
This dishwasher may be fed with either hot (max. 60°C)
or cold water.
Nevertheless we advise you a cold water supply.
A hot water supply is not always efficient with very
soiled crockery as it shortens the washing programmes
a lot.
Feeding the appliance with a hot water supply (max.
60°C) will allow you to obtain considerably shorter
programmes.
For making the connection itself, the coupling nut fitted to
the machine's supply hose is designed to screw onto a
3/4 inch BSP thread.
The water pressure must be within the limits given in
the technical specifications, as it will not function
correctly if pressure is outside these specifications.
The water supply hose is fitted with a safety device,
which prevents water from entering the machine
should the inner hose split, due to wear.
The problem is signalled by a red indicator which
appears in window (B).
If this happens, close the water tap and have the hose
replaced.
Warning: the nut (A) must be properly fitted so as to
avoid water leaks.
A
1
B
CA13
2
A
C
B
5
Note: (Only for water supply hoses with lock-fast
safety device to prevent inadvertent loosening).
To detach the hose press yellow lever (C) and turn the
nut anti-clockwise
.
Note: the end of the hose connected to the machine can
be positioned as required, by simply slackening the nut.
Re-tighten the nut securely to avoid water leaks.
CA06
Avoid bends or kinks in the hose, which could prevent
or slow down the flow of water.
If the machine is connected to new pipes or pipes
which have not been used for a long time, you are
advised to run the water for a few minutes before
connecting the inlet hose. This will prevent deposits of
sand or rust clogging the inlet hose filter.
