  Summary of Contents for Westinghouse 907 series

  • Page 2 CONTENTS Page Introduction • Installation Double Checks • Safety Warnings • How your dishwasher works Operating Instructions • Quick Start • Program Selection Guide • Operation Selection Guide • Option Selection Guide Loading your dishwasher • Dish Care & Preparation •...
  • Page 3: Safety Warnings

    INTRODUCTION Congratulations on the purchase of your new dishwasher. We trust you will be delighted with it. Please read this instruction book carefully. It will give you the information you need to: • care for, and • use your dishwasher Contact your nearest Authorised Service Centre if you need advice.
  • Page 4: How Your Dishwasher Works 2

    INTRODUCTION How your dishwasher works: The way your dishwasher works is quite simple • Water enters the unit through an inlet hose & a water valve. • A level switch controls the amount of water received into the unit. A dishwasher does not fill up, like a washing machine.
  • Page 5: Quick Start

    OPERATING INSTRUCTIONS Quick Start To run your dishwasher, follow these basic steps • Load Dishwasher • Add Detergent • Fill Rinse Aid Rinse aid must be filled to ensure good drying performance • Close the dishwasher door. • Select & start desired wash program. N ORMAL •...
  • Page 6: Program Selection Guide 4

    OPERATING INSTRUCTIONS Program selection Guide Models 907, 915 & 925 Wash times are approximate and vary by options selected. An automatic sensor checks the incoming water temperature for the main wash of each cycle, delaying the timer if necessary, until the water is hot enough.
  • Page 7: Operation Selection Guide 5

    OPERATING INSTRUCTIONS Operation Selection Guide Program Button • Press this button repeatedly to select the program you want. • Press & hold this button for 3 seconds during a wash to cancel program. Start Button • Press the start button to commence the selected program. •...
  • Page 8: Option Selection Guide 6

    OPERATING INSTRUCTIONS Option Selection Guide Delay Start Option This option is available on models 915 / 925 and allows you to automatically delay starting your dishwasher from 1 to 19 hours. • Select the desired wash program. • Press the D D ELAY button repeatedly until the desired time is shown in the status window.
  • Page 9 OPERATING INSTRUCTIONS Option Selection Guide Child Lock Option (continued) Temporarily Un-Lock NORMAL Prewash Child Lock can be emporarily unlocked to access buttons Lock • Press & Hold any button for 5 seconds. NORMAL Prewash When unlocked, the “LOCK” indicator will begin to flash. Lock •...
  • Page 10: Loading Your Dishwasher

    LOADING YOUR DISHWASHER Dish Care & Preparation • Your dishwasher is not a waste disposal unit so please take care to remove all large food scraps from your dishes before loading in the dishwasher. • Place crockery and glassware so that they do not touch. This will allow them to wash. •...
  • Page 11: Loading The Upper Basket 9

    LOADING YOUR DISHWASHER Loading The Upper Basket 12 Place Setting Load The upper basket is designed for flexibility in loading a wide variety of items including cups, glasses, stemware, small plates, bowls, etc. • Load glasses in upper basket. • Load items with open ends facing down for better cleaning and draining.
  • Page 12 LOADING YOUR DISHWASHER Loading The Lower Basket 12 Place Setting Load The lower basket is designed for plates, saucers, bowls, and cookware. • Large items should be placed along the edge so they do not block the middle spray arm rotation. •...
  • Page 13: Detergent & Rinse Aid Dispenser

    DETERGENT & RINSE AID DISPENSER Safety Warning Dishwasher detergents are very alkaline and extremely dangerous if swallowed. Be careful to: • Keep them away from your eyes and skin. • Keep children away from the dishwasher when the door is open. •...
  • Page 14: Filling The Detergent Dispenser

    DETERGENT & RINSE AID DISPENSER Filling The Detergent Dispenser • Do not use normal hand washing up detergents in your dishwasher. They will cause severe foaming. • Always use fresh, good quality machine dishwashing detergent. • Fill the detergent compartment labelled 25, or compartment 15 when you use a concentrate.
  • Page 15: Maintaining Your Dishwasher

    MAINTAINING YOUR DISHWASHER Cleaning the wash filters The filters should be checked and cleaned regularly. Blocked filters will result in poor wash performance. • Open the door & remove the lower basket. • The dishwasher filter system comprises a coarse/fine filter, microfilter and a flat filter.
  • Page 16: Helpful Hints

    HELP & PROBLEM SOLVING GUIDE Helpful Hints. • The N N ORMAL ECO program saves water and energy. It runs at a lower temperature so it is not suitable for heavily soiled wash loads. To save energy, dry performance is reduced so you may have to open the door at the end of the wash cycle or even towel dry some dishes.
  • Page 17: Problem Solving Guide

    HELP & PROBLEM SOLVING GUIDE Problem Solving guide. FAULT POSSIBLE CAUSE SOLUTION Not operating No power Check power turned on / Power button is on. Power supply not connected Check plug is in & switched on Not working Check power point by using another appliance. Check fuse box &...
  • Page 18 FAULT POSSIBLE CAUSE SOLUTION Drain Too much rinse aid, soft water areas Refer to Filling the rinse aid dispenser Foam left in dishwasher Low rinse temperature. Use higher temperature program. Water left in the bottom of unit Check drain hose for kinks, sharp bends & sink Drain system blocked Draining slow trap for spigot blockage.
  • Page 19 Electrolux is not liable in the following situations (which are Warranty not exhaustive): FOR SALES IN USTRALIA AND EALAND (a) The Appliance is damaged by: APPLIANCE: ELECTROLUX DISHWASHER accident (ii) misuse or abuse, including failure to properly This document sets out the terms and conditions of product maintain or service warranties for Electrolux branded appliances.

This manual is also suitable for:

915 series925 series
