REAR AIR CONDITIONER
The appearance of rear air conditioner switch in automatic air conditioner equipped vehicle is different from that of manual air
conditioner equipped vehicle, but its functions are same.
Rear Air Conditioner
Control Switch Panel
Air Condi-
Rear Heater
tioner Switch
Switch
Rear Air Conditioner Vent
9-16
VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM
Rear Fan Speed Control
Switch
Rear Heater Vent
