4WD CHECK WARNING LIGHT AND INDICATOR*

4WD CHECK Warning Light*
This warning light comes on when the igni-
tion switch is turned to "ON" and should go
out if the system is normal. If "4WD CHECK"
warning light stays on, have the 4WD sys-
tem checked by Ssangyong Dealer or
Ssangyong Authorized Service Operation.
CAUTION
If "4WD CHECK" warning light stays on or "4WD LOW" indicator blinks
continuously, have the 4WD system checked by Ssangyong Dealer or
Ssangyong Authorized Service Operation.
4WD LOW Indicator*
When shifting the driving mode between "4WD
LOW" and "4WD HIGH", this indicator blinks
until the shifting operation is completed. After
completion of mode change to 4WD LOW,
the indicator goes on. After completion of mode
change to 4WD HIGH, the indicator goes out.
CAUTION
• Select a proper 4-wheel drive mode according to the road conditions
such as slippery, steep hills, and roughness.
• There could be mechanical noises and shocks during mode changes.
However, these are normal conditions due to mode changing operations.
• When cornering a curved road in 4WD LOW drive mode, there could
be some mechanical shocks and resistances in vehicle's drive train.
These are normal conditions due to internal resistance in drive train
when the 4WD LOW is properly working. To avoid damages to the
drive train, do not drive your vehicle with excessively high speed in
sharply curved road.
4WD High Indicator (For Part Time 4WD)
This indicator comes on when the 4WD HIGH
mode is selected by pushing 4H switch.
Shift the driving mode from 2WD to 4WD HIGH
only when the vehicle speed is under 70 km/h.
NOTE
When shifting the driving mode from 4WD LOW to 4WD HIGH, this
indicator will blinks until the shift is completed. After completion of
shift, the indicator stays on. The indicator comes on without blinking
when shifting from 2WD to 4WD HIGH.
