ADC-SDI-CC

2. Specifications

Digital Serial Output
Signal type:
Connector:
Impedance:
Return loss:
Jitter:
Peak to peak signal level:
Composite and Y/C Input:
Signal type:
Connector:
Impedance:
Signal level:
Return loss:
Component and RGB Input:
Signal rate:
Signal type:
Connector:
Impedance:
Signal level:
Return loss:
Processing Performance:
Signal path:
Sampling:
Luma/Chrome separation:
Video bandwidth:
Hue Accuracy
Colour Saturation Accuracy
Luminance Nonlinearity
SNR ( :
unified weighted)
Diff. gain:
Diff. phase:
Video processing delay
Power:
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
E-mail: support@network-electronics.com – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
SMPTE 259M / ITU-R BT.601
BNC
75 ohm
>15dB @ 270MHz
< 0.2UI
800mV ± 80mV
Composite video, PAL 625/50Hz or NTSC 525/60Hz
Y / C (S-video)
BNC
75 ohm
1Vp-p
>40dB
625/50Hz or 525/60Hz
RGB without setup, with separate sync.
SMPTE / EBU Y, Cr, Cb
BNC
75 ohm
Y = 1Vp-p. Cb, Cr, R, G, B = 0.7Vp-p
>40dB
10 bits
27MHz, 2 x oversampling
selectable 5 line adaptive comb filter or chroma trap filter
6MHz
0.5° typical
0.8% typical
0.6% typical
66dB typical
<1.0%
<1.0°
3 video lines
+5V DC / 2.75W
-15V DC / 0.5W
Rev. 3
DATE: 23 July 2008
6
