- Page 1 Flashlink User Manual ADC-SDI NTSC/PAL to SDI encoder Rev. 6...
-
Page 2: Revision History
ADC-SDI Rev. 6 Network Electronics AS P.O. Box 1020 N-3204 Sandefjord, Norway Phone: +47 33 48 99 99 Fax: +47 33 48 99 98 Email: support@network-electronics.com www.network-electronics.com Support Phone: +47 90 60 99 99 Revision history Current revision of this document is the uppermost in the table below. -
Page 3: Table Of Contents
5.1 Module status - Light Emitting Diodes................11 5.2 Switches ...........................11 5.3 Interface with GYDA or other controllers................14 General environmental requirements for Network Electronics equipment ....17 Product Warranty...................... 18 Appendix A Materials declaration and recycling information........19 A.1 Materials declaration......................19 A.2 Environmentally-friendly use period.................19... -
Page 4: Product Overview
The Flashlink ADC-SDI is a high-quality 10-bit NTSC/PAL composite 4:2:2 to digital video converter. ADC-SDI user parameters can be changed via switches on the unit, or via the GYDA control interface. To aid digital to analogue conversion of the digital output the ADC-SDI may generate a white pulse to mark first field of an 8-field-PAL/4-field-NTSC signal. -
Page 5: Specifications
ADC-SDI Rev. 6 2 Specifications 2.1 Digital Serial Output Output format 270 Mb/s scrambled NRZI Output level 800 mV nominal Return loss > 15 dB 2.2 Analogue input, both PAL (625/50) and NTSC (525/60) Input formats CVBS S-Video Input level 1000 mV nominal ±... -
Page 6: Configuration
EEPROM as soon as it is detected. 3.4 Channel search modes ADC-SDI will search for an input-signal, try to identify it and hopefully find a signal it can lock ADC-SDI has 2 input channels with 3 types of input: −... -
Page 7: Luma / Chroma Separation Filters
− CVBS Ch. 1 ADC-SDI searches for CVBS input on channel 1, and ignores other input types. When a signal is detected, it tries to lock to it, and stops searching. -
Page 8: Selection Of Luma/Chroma Separation Filter
ADC-SDI Rev. 6 3.6 Selection of luma/chroma separation filter Filter type Luma Bandwidth Limitations Applications No comb filter PAL ~= 4MHz Limited bandwidth. VHS, Umatic and other sources with lower NTSC ~= 3MHz Cross colour artefacts bandwidth visible in luma... -
Page 9: Connections
ADC-SDI Rev. 6 4 Connections The ADC-SDI has its own connector module: ADC-SDI-C1, mounted at the rear of the sub- rack. Figure 2: ADC-SDI-C1 connector module. 4.1 Mounting the connector module If the connector module is purchased separately, it should be mounted as described in the user manual for the sub-rack frame FR-2RU-10-2. -
Page 10: Adc-Sdi Rev
ADC-SDI Rev. 6 Figure 3: ADC-SDI simplified silkscreen (figure not to scale). network-electronics.com | 10... -
Page 11: Operation
Figure 3. A switch is on when the tap is displaced in direction of the back-plane. The ADC-SDI card is shipped with all switches, except switch 1, 6 and 10, in the Off-position. Switch number 10 should always be in the On-position. The switches are discussed in logical rather than numerical order. - Page 12 5.2.1 Switch 1 - Manual mode Switch 1 is the manual mode switch. If set to on, the ADC-SDI is primarily assumed to be operated with switches alone. If set to off, the ADC-SDI is assumed to be used with a GYDA controller.
- Page 13 5.2.8 Switch 10 - Programming mode Switch 10 is purely used for service upgrade of the ADC-SDI card. It should always be in the on position. If switch 10 is in the off position, the CardState LED will light up red, and the ADC-SDI card will enter programming mode.
-
Page 14: Interface With Gyda Or Other Controllers
Table 6: All commands available to the user 5.3.1 The '?' command According to the Flashlink-protocol, no card can use the RS422-bus before the '?' (hello) command is sent the card at least once. The response from ADC-SDI will be: xxxxADC-SDI\ PIC sw rev X.X.X\ FPGA sw rev X\ Protocol ver X.X... - Page 15 CVBS Ch. 1, CVBS Ch. 2 or S-Video with Luma on Ch. 1 and Chroma on Ch. 2. The other three commands will force the ADC-SDI-card to search for only one of the three input types.
- Page 16 ADC-SDI Rev. 6 Status of Status string Comment Channel Channel Select: Automatic Search for any legal type of input signal on Select the 2 input channels. Channel Select: Ch. 1 CVBS Search for CVBS Ch. 1 Channel Select: Ch. 2 CVBS Search for CVBS Ch.
-
Page 17: General Environmental Requirements For Network Electronics Equipment
ADC-SDI Rev. 6 General environmental requirements for Network Electronics equipment The equipment will meet the guaranteed performance specification under the following environmental conditions: Operating room temperature range: 0°C to 40°C Operating relative humidity range: Up to 90% (non-condensing) The equipment will operate without damage under the following environmental... -
Page 18: Product Warranty
Rev. 6 Product Warranty The warranty terms and conditions for the product(s) covered by this manual follow the General Sales Conditions by Network Electronics AS. These conditions are available on the company web site of Network Electronics AS: www.network-electronics.com network-electronics.com | 18... -
Page 19: Appendix A Materials Declaration And Recycling Information
See http://www.aeanet.org/GovernmentAffairs/qfLeOpAaZXaMxqGjSFbEidSdPNtpT.pdf for an unofficial translation of the draft guidance. For our own products, Network Electronics has chosen to use the 50 year figure recommended in this draft regulation. Network Electronics suggests the following statement on An “Environmentally Friendly Use Period”... -
Page 20: Recycling Information
Please contact Network Electronics’ Customer Support for assistance with recycling if this site does not show the information you require. Where it is not possible to return the product to Network Electronics or its agents for recycling, the following general information may be of assistance: −... -
Page 21: Ec Declaration Of Conformity
ADC-SDI Rev. 6 EC Declaration of Conformity MANUFACTURER Network Electronics AS P.B. 1020, N-3204 SANDEFJORD, Norway AUTHORISED REPRESENTATIVE Not applicable (Established within the EEA) MODEL NUMBER(S) ADC-SDI DESCRIPTION NTSC/PAL to SDI encoder DIRECTIVES this equipment complies with LVD 73/23/EEC EMC 2004/108/EEC...
