ADC-SDI

2 Specifications

2.1 Digital Serial Output

Output format
Output level
Return loss

2.2 Analogue input, both PAL (625/50) and NTSC (525/60)

Input formats
Input level
Return loss

2.3 Processing performance

Signal path
Video processing delay

2.4 Electrical

Input Voltage
Power Consumption
270 Mb/s scrambled NRZI
800 mV nominal
> 15 dB
CVBS
S-Video
1000 mV nominal ± 10 mV
> 35 dB
10 bits
2 video lines
DC 5 V
DC –15 V
< 2.6 W
Rev. 6
network-electronics.com | 5
