ETH100

3 Specifications

Optical input:

Sensitivity:

Optical wavelength:

Transmission circuit fibre:

Return loss:

Detector damage threshold:

Max input power:

Connector:

Optical output:

Transmission circuit fibre:

Light source:

Optical wavelength :

Ethernet:

2 x 10BaseT/100BaseTx on RJ-45 connectors, compliant with IEEE 802.3 and IEEE 802.3u,

speed auto sensing, auto MDI/MDI-X

Electrical:

Power:

Control:

Better than –32dBm

1200nm – 1610nm

Multi mode 50/125 um, single mode 9/125um compatible

>40dB with single mode fibre

>+1dBm

-6 dBm

SC/UPC

Single Mode

F-P/DFB Laser

See Laser Options below

+5V DC/4W and –15VDC/0.1W

Control system for access to setup and module status with

BITE (Built-In Test Equipment)

network-electronics.com | 6

Rev. 7
