Summary of Contents for Network Electronics Flashlink ETH100
- Page 1 Flashlink User Manual ETH100 Fast Ethernet Fibre Converter Rev. 7...
-
Page 2: Revision History
ETH100 Rev. 7 Network Electronics ASA Thorøya P.O. Box 1020 N-3204 Sandefjord, Norway Phone: +47 33 48 99 99 Fax: +47 33 48 99 98 Email: support@network-electronics.com www.network-electronics.com Support Phone: +47 90 60 99 99 Revision history Current revision of this document is the uppermost in the table below. -
Page 3: Table Of Contents
7.3.2 DIP switch # 3 MDI/MDIX ..................12 7.3.3 DIP switch # 8 Sensitivity limitations ................. 12 8 Laser safety precautions ..............13 General environmental requirements for Network Electronics equipment ......................14 Product Warranty.................15 Materials declaration and recycling information Materials declaration .16 Environmentally-friendly use period .............17... -
Page 4: Product Versions
ETH100 Rev. 7 1 Product versions There are two different hardware versions of the ETH-100 card which are referred to as “Version 1” and “Version 2” in this manual. The figures below show how to distinguish the two versions from each other. The only difference is the DIP switch row, which is implemented on Version 2, this described in chapter 7.3. -
Page 5: Eth100 Rev
Rev. 7 2 Product overview The Flashlink ETH100 is a 10Base-T/100BaseTX to fibre converter module in the Network Flashlink family. The module converts a standard 10 or 100 Mbit/s Ethernet signal on copper to fibre suitable for long haul applications. The module has two electrical Ethernet ports. The ports are independent of each other, and can be used for 10 or 100Mbit/s Ethernet. -
Page 6: Specifications
ETH100 Rev. 7 3 Specifications Optical input: Sensitivity: Better than –32dBm Optical wavelength: 1200nm – 1610nm Transmission circuit fibre: Multi mode 50/125 um, single mode 9/125um compatible Return loss: >40dB with single mode fibre Detector damage threshold: >+1dBm Max input power:... -
Page 7: Laser Options
ETH100 Rev. 7 4 Laser options The ETH100 card is available in the following versions: ETH100-13T -7.5dBm 1310± 40nm -7.5 dBm F-P laser ETH100-13T 0 dBm 1310± 40nm 0 dBm F-P laser 1550± 40nm 0 dBm DFB laser ETH100-15T 0 dBm... -
Page 8: Switch Operation
Rev. 7 5 Switch operation The ETH100 contains a complete non blocking 3 port Ethernet switch. One port is the fibre port; the two other ports are the electrical ports. The fibre port is always running in 100 Mbit/s full duplex operation, the two electrical ports can run in 10 or 100Mbit/s, full or half duplex. -
Page 9: Connector Module
ETH100 Rev. 7 6 Connector module The ETH100 has a dedicated connector module: ETH100-C1. This module is mounted at the rear of the sub-rack. 6.1 Mounting the connector module The details of how the connector module is mounted, is found in the user manual for the Flashlink frame FR-2RU-10-2. -
Page 10: Status Indicators
ETH100 Rev. 7 7 Status indicators 7.1 Front Panel LEDs The status of the module can be easily monitored visually by the LEDs at the front of the module. Description Green light Red light No light STAT Module Module self-test is OK... -
Page 11: Indicators For Electrical Ethernet Ports
The status of the electrical Ethernet ports is indicated with 6 Light Emitting Diodes (LEDs), 3 for each electrical port. The LEDs are located in the upper left corner of the ETH100 board, so you have to remove the front cover of the sub rack to inspect them. -
Page 12: Dip Switches - Version 2
ETH100 Rev. 7 7.3 DIP switches - Version 2 The tables, on the next page, explain the functionality of the DIP switches shown in the figure below. DIP switch # 1 DIP switch # 8 DIP switch # Description Auto... -
Page 13: Laser Safety Precautions
8 Laser safety precautions These are guidelines to limit hazards from laser exposure. All the available EO (including ETH100) units in the Flashlink range include a laser. Therefore this note on laser safety should be read thoroughly. The lasers emit light at wavelengths from 1270nm up to 1610nm. This means that the human eye cannot see the beam, and the blink reflex cannot protect the eye. -
Page 14: General Environmental Requirements For Network Electronics Equipment
ETH100 Rev. 7 General environmental requirements for Network Electronics equipment The equipment will meet the guaranteed performance specification under the following environmental conditions: Operating room temperature range: 0°C to 40°C Operating relative humidity range: Up to 90% (non-condensing) The equipment will operate without damage under the following environmental... -
Page 15: Product Warranty
Rev. 7 Product Warranty The warranty terms and conditions for the product(s) covered by this manual follow the General Sales Conditions by Network Electronics ASA. These conditions are available on the company web site of Network Electronics ASA: www.network-electronics.com network-electronics.com | 15... - Page 16 ETH100 Rev. 7 Materials declaration and recycling information Materials declaration For product sold into China after 1st March 2007, we comply with the “Administrative Measure on the Control of Pollution by Electronic Information Products”. In the first stage of this legislation, content of six hazardous materials has to be declared. The table below shows the required information.
-
Page 17: Environmentally-Friendly Use Period
See http://www.aeanet.org/GovernmentAffairs/qfLeOpAaZXaMxqGjSFbEidSdPNtpT.pdf for an unofficial translation of the draft guidance. For our own products, Network Electronics has chosen to use the 50 year figure recommended in this draft regulation. Network Electronics suggests the following statement on An “Environmentally Friendly Use Period”... -
Page 18: Recycling Information
Please contact Network Electronics’ Customer Support for assistance with recycling if this site does not show the information you require. Where it is not possible to return the product to Network Electronics or its agents for recycling, the following general information may be of assistance: −... -
Page 19: Ec Declaration Of Conformity
ETH100 Rev. 7 EC Declaration of Conformity MANUFACTURER Network Electronics ASA P.B. 1020, N-3204 SANDEFJORD, Norway AUTHORISED REPRESENTATIVE Not applicable (Established within the EEA) ETH100 MODEL NUMBER(S) DESCRIPTION Fast Ethernet Fibre Converter DIRECTIVES this equipment complies with LVD 73/23/EEC EMC 89/336/EEC...
