- Page 1 Flashlink User Manual SDI-EO-2 / SDI-EO-2-RC Dual SDI Electrical to Optical Converter Rev. 2...
-
Page 2: Revision History
SDI-EO-2 /SDI-EO-2-RC Rev. 2 Network Electronics ASA Thorøya P.O. Box 1020 Sandefjord, Norway Phone: +47 33 48 99 99 Fax: +47 33 48 99 98 E-mail: support@network-electronics.com www.network-electronics.com Service Phone: +47 90 60 99 99 Revision history Current revision of this document is the uppermost in the table below. -
Page 3: Table Of Contents
SDI-EO-2 /SDI-EO-2-RC Rev. 2 Contents Revision history................2 1 Product overview................. 4 1.1 Product versions ..................5 2 Specifications ................6 2.1 Optical output.....................6 2.2 Electrical ......................6 2.3 Electrical input.....................6 2.4 Electrical output ..................7 2.5 Standards ....................7 3 Format configuration..............8 4 Connector module .............. -
Page 4: Product Overview
SDI-EO-2 /SDI-EO-2-RC Rev. 2 1 Product overview The Flashlink SDI-EO-2 /SDI-EO-2-RC is an electrical to optical converter module providing high performance media conversion for various signal formats from 19.4Mbps up to 540Mbps. Unmatched signal accuracy, even in critical applications with pathological signal patterns makes the SDI-EO-2 / SDI-EO-2-RC the first choice for all optical transport demands. -
Page 5: Product Versions
SDI-EO-2 /SDI-EO-2-RC Rev. 2 1.1 Product versions SDI-EO-2 is available in the following versions: Part No. Wavelength Laser type Output power SDI-EO-2-13T 1310 nm -7.5 dBm -7.5dBm SDI-EO-2-15T 0dBm 1550 nm 0 dBm SDI-EO-2-C1xxx 1xxx nm 0 dBm In addition, SDI-EO-2-RC xxxxxxxx also contains reclockers and cross point functionality. -
Page 6: Specifications
SDI-EO-2 /SDI-EO-2-RC Rev. 2 2 Specifications 2.1 Optical output Transmission circuit fibre 9/125µm Single Mode Light source F-P / DFB laser Optical power -7.5dBM @ 1310nm (F-P laser) 0 dBm (DFB laser) Optical centre wavelength 1310nm or 1550nm. ±20nm (F-P lasers) Max. -
Page 7: Electrical Output
SDI-EO-2 /SDI-EO-2-RC Rev. 2 2.4 Electrical output Number of outputs Connector Impedance 75 ohms Return loss >15dB @ 540MHz Jitter (UI = Unit Interval) Max. 0.2UI 0.8V ±0.1V Peak to peak signal level Signal polarity Non-inverting 2.5 Standards Supported standards for electrical and optical ports: SMPTE: SMPTE 259M, SMPTE 297M, SMPTE 305M, SMPTE 310M. -
Page 8: Format Configuration
SDI-EO-2 /SDI-EO-2-RC Rev. 2 3 Format configuration The SDI-EO-2 can support a number of different broadcast formats. The correct configuration can either be set with DIP switch or with the GYDA-SC System Controller. The layout of SDI-EO-2 is shown in the drawing below with the DIP switch to the upper left position. -
Page 9: Connector Module
SDI-EO-2 /SDI-EO-2-RC Rev. 2 4 Connector module The SDI-EO-2 / SDI-EO-2-RC has a dedicated connector module: HD-EO-2-C1. This module is mounted at the rear of the frame. The module is shown in the figure below. Figure 3: Connector module for SDI-EO-2. In typical use, a SDI-EO-2(-RC) / SDI-OE-2(-RC) module at each end will be used. -
Page 10: Terminal Format Support
SDI-EO-2 /SDI-EO-2-RC Rev. 2 4.2 Terminal format support The different input and output ports on SDI-EO-2 / SDI-EO-2-RC can support a number of formats. The table below shows which signal formats are supported on the selected terminals. Terminal format support: Terminal Function Supported Format... -
Page 11: Module Status
SDI-EO-2 /SDI-EO-2-RC Rev. 2 5 Module status The status of the module can be monitored in three ways. 1. GYDA-SC System Controller (optional) 2. GPI at the rear of the frame 3. LEDs at the front of the frame Of these three, the GPI and the LEDs are mounted on the module itself, whereas the GYDA-SC System Controller is a separate module giving detailed information on the card status. -
Page 12: Front Panel - Status Monitoring
SDI-EO-2 /SDI-EO-2-RC Rev. 2 5.2 Front panel – Status monitoring The status of the module can be easily monitored visually by the LEDs at the front of the module. The LEDs are visible through the front panel as shown in the figure below. -
Page 13: Laser Safety Precautions
SDI-EO-2 /SDI-EO-2-RC Rev. 2 6 Laser safety precautions A guideline to limit hazards from laser exposure follows: All the available EO units in the Flashlink range include a laser. Therefore, please read the note on laser safety thoroughly. The lasers emit light wavelength greater than 1270 nm. This means that the human eye cannot see the beam, and the blink reflex cannot protect the eye. -
Page 14: General Environmental Requirements For Flashlink Equipment
SDI-EO-2 /SDI-EO-2-RC Rev. 2 General environmental requirements for Flashlink equipment 1. The equipment will meet the guaranteed performance specification under the following environmental conditions - Operating room temperature range 0°C to 40°C - Operating relative humidity range < 90% (non-condensing) 2. -
Page 15: Certificate Of Conformity
SDI-EO-2 /SDI-EO-2-RC Rev. 2 Certificate of Conformity Network Electronics ASA Company Registration Number: N-3204 Sandefjord NO 976 584 201 MVA Norway Declares under sole responsibility that the product: Product Name SDI-EO-2 Product Description Dual SDI Electrical to Optical Converter To which this declaration relates are of Norwegian origin and are in conformity with... -
Page 16: Product Warranty
SDI-EO-2 /SDI-EO-2-RC Rev. 2 Product Warranty The warranty terms and conditions for the product(s) covered by this manual follow the General Sales Conditions by Network Electronics ASA. These conditions are available on the company web site of Network Electronics ASA: www.network-electronics.com... -
Page 17: Materials Declaration And Recycling Information
For our own products, Network Electronics has chosen to use the 50 year figure recommended in this draft regulation. Network Electronics suggests the following statement on An “Environmentally Friendly Use Period” (EFUP) setting out normal use: EFUP is the time the product can be used in normal service life without leaking the hazardous materials. -
Page 18: Recycling Information
Customer Support for assistance with recycling if this site does not show the information you require. Where it is not possible to return the product to Network Electronics or its agents for recycling, the following general information may be of assistance: Before attempting disassembly, ensure the product is completely disconnected from power and signal connections.
