HD-OE-2/HD-OE-L-2/HD-OE-2-M

2 Specifications

2.1 Optical input

Data rate optical
Sensitivity
HD-SDI (1485Mbps)
HD-SDI (1485Mbps)
SDI (270Mbps)
Detector overload threshold
Detector damage threshold
Optical wavelength
Transmission circuit fibre
Transmission circuit fibre
Connector return loss
Connector

2.2 Electrical

Power
Control

2.3 Electrical output

Number of outputs
Connector
Impedance
Return loss
Jitter (UI = Unit Interval)
Peak to peak signal level
Signal polarity

2.4 Standards

Supported standards for electrical and optical ports:
SMPTE:
DVB-ASI:
19.4 – 1485 Mbps.
Better than -20dBm
Better than -23dBm (HD-OE-L-2)
Better than -25dBm
Min. -6dBm
> +1dBm
2nd and 3rd optical window,
1200 - 1620nm.
9/125um Single Mode
50/125um Multi Mode (HD-OE-2-M)
>40dB w/ SM fibre.
SC/UPC.
+5V DC / 3.2W Max.
Control system for access to setup and module status
with BITE (Built-In Test Equipment).
1.
BNC.
75 ohm.
>15dB @ 1485MHz.
Max. 0.2UI.
0.8V ±0.1V.
1 non-inverting,
1 inverting.
SMPTE 292M, SMPTE 259M, SMPTE 297M, SMPTE
305.2M,
SMPTE 310.
EN50083-9.
Rev. 1
