- Page 1 Flashlink User Manual HD-OE-2/HD-OE-L-2/HD-OE-2-M Dual HD-SDI Optical to Electrical Converter / Dual HD-SDI Long-haul Optical to Electrical Converter/ Dual HD-SDI Optical to Electrical Converter for multi mode Rev. 1...
-
Page 2: Revision History
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 Network Electronics ASA Thorøya P.O. Box 1020 N-3204 Sandefjord, Norway Phone: +47 33 48 99 99 Fax: +47 33 48 99 98 Email: support@network-electronics.com www.network-electronics.com Support Phone: +47 90 60 99 99 Revision history Current revision of this document is the uppermost in the table below. -
Page 3: Table Of Contents
5.1 GPI Alarm – module status outputs..................10 5.2 Front panel – Status monitoring ..................11 6 Laser safety precautions..................12 General environmental requirements for Network Electronics equipment ....13 Product Warranty...................... 14 Appendix A Materials declaration and recycling information........15 A.1 Materials declaration......................15 A.2 Environmentally-friendly use period.................15... -
Page 4: Product Overview
Rev. 1 1 Product overview The Flashlink HD-OE-2 is a dual multi bit-rate optical to electrical converter module providing high performance media conversion for various signal formats from 19.4Mbps up to 1485Mbps. This state of the art unit offers a high sensitivity PIN diode technology. -
Page 5: Specifications
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 2 Specifications 2.1 Optical input Data rate optical 19.4 – 1485 Mbps. Sensitivity HD-SDI (1485Mbps) Better than -20dBm HD-SDI (1485Mbps) Better than -23dBm (HD-OE-L-2) SDI (270Mbps) Better than -25dBm Detector overload threshold Min. -6dBm Detector damage threshold >... -
Page 6: Configuration
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 3 Configuration 3.1 Format configuration The HD-OE-2 can support a number of different broadcast formats. The correct configuration can either be set with a DIP switch or with the GYDA Control System. The layout of HD-OE-2 is shown in the drawing below with the DIP switch to the upper left position. Figure 2 - HD-OE-2 board layout DIP switch configuration must be set according to the table below: Switch # Label Function, DIP = ON Function, DIP = OFF... -
Page 7: Configuration Examples
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 3.2 Configuration examples Normal operation. No change over functionality. Input 1 is selected Normal operation. No change over functionality. Input 2 is selected Figure 3 - Normal operation. Signal on input 2 not present Change over. Priority on input 2 Change over. -
Page 8: Connector Module
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 4 Connector module The HD-OE-2 has a dedicated connector module: HD-EO-2-C1. This module is mounted at the rear of the sub-rack. The module is shown in the figure below. Figure 5 - Connector module for HD-OE-2 In typical use a HD-EO-2 / HD-OE-2 module at each end will be used. Two channels simultaneously can be converted from optical to electrical channels. -
Page 9: Terminal Format Support
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 4.2 Terminal format support The different input and output ports on HD-OE-2 can support a number of formats. The table below shows which signal formats are supported on the selected terminals. Terminal format support: Terminal Function Supported Format Mode OPT1 Optical output... -
Page 10: Module Modus
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 5 Module modus The status of the module can be monitored in three ways. 1. GYDA System Controller (optional). 2. GPI at the rear of the sub-rack. 3. LED’s at the front of the sub-rack. Of these three, the GPI and the LEDs are mounted on the module itself, whereas the GYDA System Controller is a separate module giving detailed information on the card status. -
Page 11: Front Panel - Status Monitoring
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 5.2 Front panel – Status monitoring The status of the module can be easily monitored visually by the LED’s at the front of the module. The LEDs are visible through the front panel as shown in the figure below. Figure 7 - Front panel indicators for the HD-OE-2 The HD-OE-2 has 4 LEDs each showing a status corresponding to the GPI pinning. -
Page 12: Laser Safety Precautions
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 6 Laser safety precautions These are guidelines to limit hazards from laser exposure. All the available EO units in the Flashlink range include a laser. Therefore this note on laser safety should be read thoroughly. The lasers emit light at wavelengths from 1310nm up to 1550nm. This means that the human eye cannot see the beam, and the blink reflex cannot protect the eye. -
Page 13: General Environmental Requirements For Network Electronics Equipment
HD-OE-2/HD-OE-L-2/HD-OE-2-M Rev. 1 General environmental requirements for Network Electronics equipment The equipment will meet the guaranteed performance specification under the following environmental conditions: Operating room temperature range: 0°C to 40°C Operating relative humidity range: <90% (non-condensing) The equipment will operate without damage under the following environmental... -
Page 14: Product Warranty
Rev. 1 Product Warranty The warranty terms and conditions for the product(s) covered by this manual follow the General Sales Conditions by Network Electronics ASA. These conditions are available on the company web site of Network Electronics ASA: www.network-electronics.com network-electronics.com | 14... -
Page 15: Appendix A Materials Declaration And Recycling Information
See http://www.aeanet.org/GovernmentAffairs/qfLeOpAaZXaMxqGjSFbEidSdPNtpT.pdf for an unofficial translation of the draft guidance. For our own products, Network Electronics has chosen to use the 50 year figure recommended in this draft regulation. Network Electronics suggests the following statement on An “Environmentally Friendly Use Period”... -
Page 16: Recycling Information
Please contact Network Electronics’ Customer Support for assistance with recycling if this site does not show the information you require. Where it is not possible to return the product to Network Electronics or its agents for recycling, the following general information may be of assistance: −...
