4. Configuration and Setup

4.1 Setting the DIP switches

The ADC-SDI-CC card has a Dual-Inline switch (DIP-switch) that has 10 individual On/Off switches.
The purpose of these switches is to provide an easy interface to some of the most used features of t
A DC-SDI-CC card, without the need of a GYDA controller. The switches are numbered from '1' towards
the top of the card, see Figure 3
Switch # Function
1 Manual mode on/off
2 Input Channel select
3 Input Channel select
4 Mark Field 1 enable on/off
5 Comb filter/Trap filter
6 Pedestal on/off
7 Reserved
8 Factory Reset on/off
9 Reserved
10 Run mode on/off
Table 1: Summary of the DIP switches. Switch 7, 9 and 10 are mainly for factory use, while switches 1, 2,
3, 4, 5 and 6 will be used when no GYDA controller is available.
Switch 1 - Manual mode
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
E-mail: support@network-electronics.com – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
Figure 3 - ADC-SDI-CC simplified silkscreen.
. A switc h is off when
Comment
When on, enables switches 2, 3, 4, 5, 6 and 8.
According to Table 3.
When on, th
When on, the comb filter is selected. When off, the trap filter
is selected.
If a setup level of 7,5 IRE is present on yo
se t to on. When black level is 0 IRE, set to off. This setting
only applies to 525 lines video st
To reset the internal EEPROM.
For factory use only
the tap is placed in direction of the front handle.
e Mark Field 1-feature enabled.
andard.
Rev. 3
DATE: 23 July 2008
he
ur analogue video,
