ETH1000-D

2 Specifications

2.1 Optical Characteristics

Optical input
Transmission circuit fibre:
Sensitivity
Optical wavelength
Detector damage threshold
Max input power
Connector
Optical Output
Transmission circuit fibre
Light source
Optical wavelength
Channel spacing
Power output
Extinction ratio

2.2 Ethernet

10BaseT/100BaseTx/1000BaseT on RJ-45 connectors. Compliant with IEEE 802.3, IEEE
802.3u, IEEE 802.3ab and IEEE 802.3z. Auto speed sensing and MDI/MDI-X.

2.3 General

Power
Control
9/125um Single Mode
Better than –25dBm
1200nm – 1610nm
> +1dBm
0dBm
SC/UPC
9/125um Single Mode
DFB DWDM Laser
1530.33nm - 1561.41nm, 40 C-band DWDM channels acc. to
ITU-T G.694.1
100GHz
0dBm (+5dBm for high power version)
> 10:1
+5V DC/2.5W and +15V DC / 0.5W
Control system for access to setup and module status with
BITE (Built-In Test Equipment)
Rev. 1
