- Page 1 Flashlink User Manual HD-EO-2 Dual High Definition Electrical to Optical Converter Rev. 3...
-
Page 2: Revision History
HD-EO-2 Rev. 3 Network Electronics ASA Thorøya P.O. Box 1020 Sandefjord, Norway Phone: +47 33 48 99 99 Fax: +47 33 48 99 98 E-mail: support@network-electronics.com www.network-electronics.com Service Phone: +47 90 60 99 99 Revision history Current revision of this document is the uppermost in the table below. -
Page 3: Table Of Contents
HD-EO-2 Rev. 3 Contents Revision history................2 1 Product overview................. 4 1.1 Product versions ..................5 2 Specifications ................6 2.1 Optical output.....................6 2.2 Electrical ......................6 2.3 Electrical input.....................6 2.4 Electrical output ..................6 2.5 Standards ....................7 3 Format configuration..............8 4 Connector module ..............9 4.1 Mounting the connector module ..............9 4.2 Terminal format support................10 5 Module status................ -
Page 4: Product Overview
High quality optical transmitters using Fabry- Perot lasers are suitable short and medium haul applications. The open system ® platform of Network Electronics flashlink system allows easy interoperability with third party fiber optical systems. The HD-EO-2 unit has also one electrical output for each channel, which reduces the need for additional DA’s. -
Page 5: Product Versions
HD-EO-2 Rev. 3 1.1 Product versions HD-EO-2 is available in the following versions: HD-EO-2-13T -7.5dBm 1310± 20nm -7.5 dBm F-P laser HD-EO-2-15T 0 dBm 1550± 6nm 0 dBm DFB laser CWDM (DFB lasers) HD-EO-2-C1470/1490 1470 ±6nm and 1490 ±6nm 0dBm HD-EO-2-C1510/1530 1510 ±6nm and 1530 ±6nm 0dBm HD-EO-2-C1550/1570... -
Page 6: Specifications
HD-EO-2 Rev. 3 2 Specifications 2.1 Optical output Transmission circuit fiber: Single Mode. Light source: F-P / DFB laser. Optical power: -7.5dBM @ 1310nm (F-P laser), 0 dBm (DFB laser). Optical centre wavelength: 1310nm ±20nm (F-P lasers) or 1550nm ±6nm (DFB lasers). Optical wavelengths for 1270/1290, 1310/1330, 1350/1370, 1390/1410, CWDM:... -
Page 7: Standards
HD-EO-2 Rev. 3 2.5 Standards Supported standards for electrical and optical ports: SMPTE: SMPTE 292, SMPTE 259M, SMPTE 297, SMPTE 305M, SMPTE 310. DVB-ASI: EN50083-9. -
Page 8: Format Configuration
HD-EO-2 Rev. 3 3 Format configuration The HD-EO-2 can support a number of different broadcast formats. The correct configuration can either be set with a DIP switch or with the GYDA Control System. The layout of HD-EO-2 is shown in the drawing below with the DIP switch to the upper left position. -
Page 9: Connector Module
HD-EO-2 Rev. 3 4 Connector module The HD-EO-2 has a dedicated connector module: HD-EO-2-C1. This module is mounted at the rear of the sub-rack. The module is shown in the figure below. Figure 3: Connector module for HD-EO-2. In typical use a HD-EO-2 / HD-OE-2 module at each end will be used. Two channels simultaneously can be converted from optical to electrical channels. -
Page 10: Terminal Format Support
HD-EO-2 Rev. 3 4.2 Terminal format support The different input and output ports on HD-EO-2 can support a number of formats. The table below shows which signal formats are supported on the selected terminals. Terminal format support: Terminal Function Supported Format Mode OPT1 Optical output... -
Page 11: Module Status
HD-EO-2 Rev. 3 5 Module status The status of the module can be monitored in three ways. 1. GYDA System Controller (optional). 2. GPI at the rear of the sub-rack. 3. LED’s at the front of the sub-rack. Of these three, the GPI and the LED’s are mounted on the module itself, whereas the GYDA System Controller is a separate module giving detailed information on the card status. -
Page 12: Front Panel - Status Monitoring
HD-EO-2 Rev. 3 5.2 Front panel – Status monitoring The status of the module can be easily monitored visually by the LED’s at the front of the module. The LED’s are visible through the front panel as shown in the figure below. Figure 5: Front panel indicators for the HD-EO-2. -
Page 13: Laser Safety Precautions
HD-EO-2 Rev. 3 6 Laser safety precautions Guidelines to limit hazards from laser exposure. ® All the available EO units in the flashlink range include a laser. Therefore this note on laser safety should be read thoroughly. The lasers emit light at 1310 nm or 1550 nm. This means that the human eye cannot see the beam, and the blink reflex cannot protect the eye. -
Page 14: General Environmental Requirements For Flashlink Equipment
HD-EO-2 Rev. 3 ® General environmental requirements for flashlink equipment 1. The equipment will meet the guaranteed performance specification under the following environmental conditions: - Operating room temperature range: 0°C to 40°C - Operating relative humidity range: < 90% (non-condensing) 2. -
Page 15: Certificate Of Conformity
HD-EO-2 Rev. 3 Certificate of Conformity Network Electronics ASA Company Registration Number: N-3204 Sandefjord NO 976 584 201 MVA Norway Declares under sole responsibility that the product: Product Name: HD-EO-2 Product Description: Dual High Definition Electrical to Optical Converter To which this declaration relates are of Norwegian origin and are in conformity with... -
Page 16: Product Warranty
HD-EO-2 Rev. 3 Product Warranty The warranty terms and conditions for the product(s) covered by this manual follow the General Sales Conditions by Network Electronics ASA. These conditions are available on the company web site of Network Electronics ASA: www.network-electronics.com... -
Page 17: Materials Declaration And Recycling Information
For our own products, Network Electronics has chosen to use the 50 year figure recommended in this draft regulation. Network Electronics suggests the following statement on An “Environmentally Friendly Use Period” (EFUP) setting out normal use: EFUP is the time the product can be used in normal service life without leaking the hazardous materials. -
Page 18: Recycling Information
Customer Support for assistance with recycling if this site does not show the information you require. Where it is not possible to return the product to Network Electronics or its agents for recycling, the following general information may be of assistance: Before attempting disassembly, ensure the product is completely disconnected from power and signal connections.
