ADC-SDI-CC
Switches 7 and 9 - Reserved
These switches are reserved and should always be in the off position.
Factory setting are switch 7 and 9 in off position.
Switch 8 - Reset to factory default
ADC-SDI-CC contains an EEPROM which stores the configuration of the card. Switch 8 can be used to
reset the EEPROM to the factory default. Follow the procedure described below.
Action
1 Power down.
2 Turn switch 8 on.
3 Power up.
4 Power down.
5 Turn switch 8 off.
6 Power up.
Table 3: Method to restore the ADC-SDI-CC card to factory settings. Remember to let some seconds pass
by each time you power down, to allow capacitors to be fully discharged.
Switch 10 - Run mode
Switch 10 is purely used for service upgrade of the ADC-SDI-CC card. It should always be in the on
position. If switch 10 is in the off position, the Card State LED will light up red, and the ADC-SDI-CC
card will enter programming mode. This causes no harm, but the card will not work in this mode.
Factory setting is switch 10 in on position.

4.2 Reset

The push-button just behind the front LEDs is a reset switch, see Figure 3 . It has the same effect as a
power off – power on cycle.
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: +47 33 48 99 99 – Fax: +47 33 48 99 98
E-mail: support@network-electronics.com – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
Switch 1 must also be turned on for this to have effect.
ADC-SDI-CC enters a special state where the EEPROM is restored to
factory default values. This is flagged by the Card State LED, which starts
to blink yellow.
If you want the DIP switches to be placed in the factory default position,
this is the time to do so: Switch 10 should, as always, be turned to the on
position. Switch 1 may be turned on or off.
The card EEPROM is now reset to factory settings.
Comment
