Configuring DIP Switch Settings

Dismounting the bottom cover of the Bridge Satellite Cradle exposes the DIP switches.
You can change the ON/OFF settings of the DIP switches to set the configuration.
Please, set after first switching OFF the power.
1 2 3 4 5 6 7 8
Important!
Note that other DIP settings are used for testing and inspection purposes. Because
of this, you should never use any DIP settings other than those described above.
Not used (Always off)
Not used (Always off)
Host Computer Interface
Setting
RS-232C
USB
Daisy Chain
Setting
Intermediate Unit
Daisy Chain Disabled/Termination
Connection Type
Setting
Host Computer
Daisy Chain
Bridge Satellite Cradle Data Rate
Setting
115,200bps
*Initial factory default setting
6
OFF
ON
*
5
OFF
ON
*
3
4
OFF
OFF
*
ON
OFF
1
2
ON
OFF
*
E-41
