ITEM
QTY
PART NO.
320
4
HS-18311
340
1
AW-18160
350
1
AW-18365
363
1
AF-18104
364
4
HB-18056
365
2
HB-18059
366
2
HN-42043
367
1
AF-18053
373
1
FM-54075
374
2
HB-44062
375
1
FM-54074
420
1
AF-20726
421
1
AF-20719
422
1
AF-20720
423
1
AF-20727
424
1
AF-20758
425
1
HS-20730
426
4
HB-20728
431
2
AX-19669
432
2
AX-19670
433
2
PL-20230
434
2
HX-18974
435
4
HS-20306
450
1
AF-17552
451
1
AF-18000
452
1
AX-17578
453
4
AX-18148
454
1
AW-17882
456
2
CW-18141
457
2
CW-18144
458
4
FM-18143
459
4
FS-18023
460
2
HB-18121
461
2
HN-11925
462
4
HN-18252
463
1
HN-60558
464
1
HS-18497
465
4
HS-18298
466
1
HS-18089
467
8
HS-18358
468
8
HW-18123
472
1
HX-18168
473
1
PD-18166
474
1
PL-18122
475
1
PL-18204
477
1
DE-18288
478
1
FM-18085
480
1
FS-18124
482
2
HX-05082
484
2
HS-41048
486
4
CA-40052
487
2
FT-18080
Cybex 530C and 530R Owner's Manual
DESCRIPTION
SCREW, 8-16 X .75", PNHD PHIL, STL, BLK
CABLE, CONSOLE HARNESS, 530R
CABLE, GROUND, UPPER, 530R
BRKT, SPRING TENSIONER, RIGHT
BUSHING, FLANGE, .375 X .469 X .25"
IDLER WHEEL, 1.88 X 1.15"
NUT, 3/8-16", FLANGED, SS, BO
BRACKET, SPRING TENSIONER, LEFT
RACE, CRANK, LEFT
BEARING, RADIAL BALL, 30 MM, W-SEALS
RACE, CRANK, RIGHT
HANDLE, RECUMBENT IFI
BRACKET, HANDLE MOUNT, RIGHT, RECUMBENT IFI
BRACKET, HANDLE MOUNT, LEFT, RECUMBENT IFI
LEVER, SEAT ADJUSTMENT, RECUMBENT IFI
WELDMENT, 90 DEG CONNECT, RECUMBENT IFI
SCREW, SHEILD, 3/8 DIA. X 1.25 X 5/16-18"
BEARING, FLANGE, NYLON 3/8" DIA. SHAFT
GRIP, HR TOP, IN-MOLDED
GRIP, HR BOTTOM, IN-MOLDED
END CAP, CONTACT GRIP
SEAL, HR GRIPS
SCREW, 6-20 X 1.12" PNHD, PHIL
WELDMENT, SEAT SHUTTLE, 530R
WELDMENT, SHUTTLE HANDLE
ASSY, CONTACT GRIP, PAIR
ASSY, SEAT SHUTTLE WHEEL
CABLE, CHR GRIPS, 530R
WHEEL, LOWER RIGHT, TAPERED
WHEEL, LOWER LEFT, BEVELED
SPACER, LOWER SHUTTLE WHEEL
PLATE, WHEEL TENSION ADJUSTER
BUSHING, FLANGED, PLASTIC, 5/16 ID"
KEPS, 10-32, HEX, STL, ZN
NUT, 5/16-18", PREVAILING TORQUE
NUT, NYLOC, .250-20, ZN, BLK
SCREW, 10-32 x .50", PNHD PHIL, BLK ZN
BOLT, 5/16-18 X .88", BTHD CAP, SS, BL
BOLT, SHEILD, 5/16 X 2.75", SCHD
BOLT, 5/16-18 X .1.25", SCHD CAP, BLK
WASHER, .344 ID X .75 OD X .125", THICK
SPRING, TORSION, SEAT SHUTTLE
SEAT, BOTTOM, 530R
ACCESSORY TRAY, 530R
CLAMP, FLAT CABLE COVER
LABEL, EXTRUSION
EXTRUSION, SEAT SHUTTLE
BRACKET, SEAT ADJUST RACK
BUMPER, SEAT LIMIT, BMR R-035
BOLT, 5/16-18 X 2", BTHD CAP, BLK OX
CAP, PLASTIC, 1 X 1", 10-14 GA.
TUBE, SEAT BACK, POWDER COATED
