Start, Stop, Clock [ F8, F8, F8..., FA, F8, F8, F8..., FC, F8, F8, F8... ]
This set differs from the others in the way in which the switch and slider will be used. (The Mode setting will be
ignored.)
Press the switch, and START [ FA ] will be transmitted. Press the switch again, and STOP [ FC will be transmitted.
The value specified as the SW value will transmitted as MIDI Clock [ F8 ] at the initial tempo (in the range of = 40
to 250), but you can use the slider to modify this while it is being transmitted.
Available types, ranges, initial values, and MIDI
transmit values (Internal)
FIX: fixed value S(L): initial setting for controller lower limit value S(H): initial setting for controller upper limit value SW: initial SW setting W/L: AW1,2/AL1-4
TYPE RANGE
[Volume] 0 to 127
[FX Dyna Mod]* 0 to 127
[Sostenuto] OFF,ON
[Brightness]* –64 to +63
[Attack Time]* –64 to +63
[Decay Time]* –64 to +63
[FX1 Depth]* 0 to 127
[FX2 Depth]* 0 to 127
[Pitch Bend] –8192 to +8191
[LFO] 0 to 127
Explanation of Internal control settings
• These settings are for controlling the internal tone generator. The TYPE name shown in the LCD will be
enclosed in [ ].
• Although these are for internal control, operating the assigned controller will also cause the correspond-
ing MIDI message to be transmitted.
• If [ FX Dyna Mod ] is selected, you will also need to specify (in the effect settings) that controller as the
modulation source ( p.50).
• These controls are not related to program parameters. Even if you use the sliders etc. to modify the
sound, the modified sound cannot be written.
• In the case of functions marked by asterisk (*), the values will be reset when program is changed in
Program mode.
VALUE
FIX S(L) S(H) SW
127 00 127 32
00 00 127 64
OFF OFF ON ON
00 –64 +63 +63
00 –64 +63 –64
00 –64 +63 –64
00 00 127 64
00 00 127 64
00 –8192 +8191 +8191
00 00 127 64
Use with a controller O: available
CONTROLLER
W/L AP AS MIDI (CC:Control Change)
O O O CC#07:Volume
O O O
CC#12:FX Control 1
O O O CC#66:Sostenuto
O O O
CC#74:Brightness
O O O CC#73:Attack Time
O O O CC#75: Deeay Time
O O O CC#93:Eff 3 Depth
O O O CC#91:Eff 1 Depth
O O O Pitch Bend
O O O CC#01:Modulation 1
Controllers / MIDI
: unavailable
61
