You can also use them to modify the sound of the SGproX.
If you connect separately sold pedals to the Assignable Pedal jack and Assignable Switch jack located on the
rear panel, you can use them as well for similar types of control.
The function can be specified independently for each controller.
The same control function will be assigned both to the switch and to the wheel (slider) of AW1 , AW2 ,
AL1 , AL2 , AL3 and AL4 respectively.
Depending on the controll type setting, you will be able to apply a specific control value by pressing the
switch while moving the wheel (slider), or to apply a specific control value fixed for each function each time
the switch is pressed.
For details refer to Controllers / MIDI (
The available controll functions, controll types, and fixed values that are specified for each function are
listed in the tables given in the Controller / MIDI section (

Assignable wheels/switches 1/2

With the factory settings, a function of Pitch Bend is selected for AW1 , and a
function of LFO is selected for AW2 .
By operating a wheel or switch, you can modify the pitch of the SGproX's sounds, or
apply vibrato or wah.
The corresponding MIDI message will also be transmitted from MIDI OUT.
For some programs, the effect may not be available.

Assignable sliders/switches 1 to 4

With the factory settings, a function of [ Brightness ] is assigned to AL1 ,
[ Decay Time ] is assigned to AL2 , [ FX2 Depth ] (effect depth) is assigned to
AL3 , and [ FX Dyna Mod ] (effect modulation) is assigned to AL4 . By operating
a wheel or switch, you can modify the sound of the SGproX.
The corresponding MIDI message will also be transmitted from MIDI OUT.
For some programs, the effect may not be available.

Assignable pedal

This is available only when a continuous pedal (XVP-10) is connected to the AP
jack on the rear panel. With the factory settings, a function of [ Volume ] is selected.
By operating the pedal you can control the volume of the SGproX.
The corresponding MIDI message will also be transmitted from MIDI OUT.

Assignable foot switch

This is available only when a pedal switch (PS-1) is connected to the AS jack on the
rear panel. With the factory settings, a function of Sostenuto is selected. By oper-
ating the pedal you can apply a sostenuto effect to the sound of the SGproX.
The corresponding MIDI message will also be transmitted from MIDI OUT.
Sostenuto is when a damper effect is applied only to the sound of those keys which were being held at
the time that the pedal switch was pressed, so that only these notes will be sustained as long as the
pedal remains pressed.
The effect will not apply to notes which are played while the sostenuto pedal remains pressed.
p.55).
p.58 and following).
Playing the SGproX
ASSIGNABLE WHEEL
AW1 AW2
ASSIGNABLE SLIDER
AL1/A AL2/a AL3/0 AL4/!
A a DELETE INSERT
ASSIGNABLE OUTPUT
DAMPER PEDAL SW R L/MONO
XVP-10 , EXP-2
ASSIGNABLE OUTPUT
DAMPER PEDAL SW R L/MONO
PS-1, PS-2 etc.
17
