Korg SP-500 Service Manual
  1. Manuals
  2. Brands
  3. Korg Manuals
  4. Musical Instrument
  5. SP-500
  6. Service manual
Korg SP-500 Service Manual

Korg SP-500 Service Manual

Hide thumbs Also See for SP-500:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
CONTENTS
1) Structural Diagram - - - - -
2) Block Diagram - - - - - - - - -
3) Circuit Diagram - - - - - - - -
4) Diagnostics - - - - - - - - - - -
5) Parts List - - - - - - - - - - - - -
S S
e e
r r
v v
i i
c c
e e
M M
S
e
r
v
i
c
e
M
SP-500
a a
n n
u u
a a
l l
a
n
u
a
l
Issued date: Feb. 7
Issued by: KORG INC.
Revision: 1.00
, 2002
th

Advertisement

loading

Related Manuals for Korg SP-500

Summary of Contents for Korg SP-500

  • Page 1 4) Diagnostics - - - - - - - - - - - 5) Parts List - - - - - - - - - - - - - Revision: 1.00 Issued date: Feb. 7 , 2002 Issued by: KORG INC.
  • Page 2 NO PART CODE PART NAME Q'TY 646081500 X-0370 4 LINKAGE KNOB-2 H40165-2 646081400 X-0370 4 LINKAGE KNOB-3 H40165-3 646081600 X-0370 4 LINKAGE KNOB-1 H40165-1 646081300 X-0370 4 LINKAGE KNOB-4 H40165-4 620038100 X-8110 KNOB L(2 LINKAGE) H40148-2 620038200 X-8110 KNOB L H40148-1 646081700 X-8110 KNOB L (4 LINKAGE) H40148-8 646081800 X-8110 KNOB L H40148-9...
  • Page 3 NO PART CODE PART NAME Q'TY 620021600 X-825M POWER SW KNOB BK E40264 646082100 X-224 SLIDE VR KNOB NO.3 E4028 620034700 X-610 ENCODER KNOB(GRAY)E40466 313005600 LCD DG-24064-2-S1MBLA-H(AMBER) 641041655 X-0370 PANEL KOC-C10266 645053263 X-0370 SIDE BOARD L D30231-1 645053264 X-0370 SIDE BOARD R D30231-2 420006700 KEYBOARD 88NOTE TP/31+PCB 641041678 X-0370 FRONT BAR KOC-C20370 646045300 X-181 MUSIC STAND HOLDER...
  • Page 9 SP500 Test Mode How to start the test mode: 1) [FUNCTION] + [TEMPO DOWN] &[POWER ON] : Full test 2) [FUNCTION] + [TEMPO UP] &[POWER ON] : MIDI test Skip 3) [FUNCTION] + [METRONOME] & [POWER ON] : Internal test Skip 4) [START/STOP] + [INTRO/ENDING1] &...
